125
Control Panel
Control Panel Menu Options
02/28/2012 P1043301-002
IP PROTOCOL
The S4M LCD menu
will appear as:
OBTAIN IP ADDRESS
followed by:
CHANGE IP PROTOCOL
The allows you to see if the user
(permanent) or the server (dynamic)
selects the IP address.
IP ADDRESS
The S4M LCD menu
will appear as:
CHANGE IP ADDRESS
This allows you to modify this
setting, only when Permanent is
select for OBTAIN IP ADDRESS.
SUBNET MASK
The S4M LCD menu
will appear as:
CHANGE SUBNET
This allows you to view the subnet
mask.
DEFAULT GATEWAY
The S4M LCD menu
will appear as:
CHANGE GATEWAY
The ZT230 LCD
menu will appear as:
GATEWAY
This allows you to view the default
gateway.
MAC ADDRESS This allows you to view the MAC
address for the current wireless
radio card.
RESET NETWORK
The ZT230 LCD
menu will appear as:
LOAD DEFAULTS
This allows you to re-initialize the
wireless radio card and the print
server (wired or wireless).
Table 20 • Wired Network Parameters
XiIIIPlus
Z4Mplus/Z6Mplus
105SL
PAX4
Xi4
ZM400/ZM600
S4M
ZE500
ZT230
LCD Option Details
