Control Panel
Control Panel Menu Options
124
P1043301-002 02/28/2012
Control Panel Menu Options
Control Panel (or Liquid Crystal Display—LCD) menu options only appear if a print server is
installed. The control panel parameters are somewhat different for different printers. Refer to
the user guide for your printer for specific instructions on how to modify the control panel
parameters.
Wired Network Parameters on the LCD
Table 20 identifies the wired network parameters available on your Zebra XiIIIPlus,
Z4Mplus/Z6Mplus, 105SL, PA X 4, Xi4, ZM400/ZM600, S4M, ZE500, and ZT230
printers/print engines with a print server installed.
Note • The ZT210 and ZT220 printers have the same parameters available, but do not have
control panels. Refer to the Zebra ZT210/ZT220/ZT230 User Guide for more information on
how to access these parameters.
Table 20 • Wired Network Parameters
XiIIIPlus
Z4Mplus/Z6Mplus
105SL
PAX4
Xi4
ZM400/ZM600
S4M
ZE500
ZT230
LCD Option Details
LIST NETWORK Prints a network configuration label.
WIRED PS CHECK? This tells if the printer searches for a
wired print server at bootup.
PRIMARY NETWORK
The ZT230 LCD
menu will appear as:
PRIMARY PRINT
SERVER
This allows you to see if the printer
is using an IP setting from the
wireless or a wired print server at
bootup.
LOAD LAN FROM?
The Xi4 and the
ZM400/ZM600
LCD menu will
appear as:
LOAD FROM EXT?
This determines if the printer uses
IP settings from the printer or the
print server at bootup.
ACTIVE PRINTSRVR This allows you to see which print
server is being used.
