ZebraNet® Wired and Wireless Print Servers User Guide P1043301-002 Rev.
© 2012 ZIH Corp. The copyrights in this manual and the software and/or firmware in the label printer described therein are owned by ZIH Corp. Unauthorized reproduction of this manual or the software and/or firmware in the label printer may result in imprisonment of up to one year and fines of up to $10,000 (17 U.S.C.506). Copyright violators may be subject to civil liability. This product may contain ZPL®, ZPL II®, and ZebraLink™ programs; Element Energy Equalizer® Circuit; E3®; and Monotype Imaging fonts.
Contents About This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Who Should Use This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 How This Document Is Organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents 2 • Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 External ZebraNet 10/100 Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Illustration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents Defaulting ALL Print Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using WebView . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using ZebraNet Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using a ZPL Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents 8 • Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123 Control Panel Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Wired Network Parameters on the LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Wireless Network Parameters on the LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126 9 • Hardware Troubleshooting . . . . . . . . .
About This Document This section provides you with contact information, document structure and organization, and additional reference documents. Contents Who Should Use This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 How This Document Is Organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About This Document Who Should Use This Document Who Should Use This Document This User Guide is intended for anyone who will install and work with Zebra print servers (PS).
About This Document How This Document Is Organized How This Document Is Organized This User Guide is set up as follows: 02/28/2012 Section Description Introduction on page 15 This chapter provides a high-level overview of Zebra’s wired and wireless print servers, installation types, standard network configurations, and how to work with the print servers. Installation on page 31 This chapter provides information on how to install the Zebra’s wired and wireless print servers.
About This Document Contacts Contacts Technical Support via the Internet is available 24 hours per day, 365 days per year. Web Site: www.zebra.com Self Service Knowledge Base: www.zebra.com/knowledgebase Online Case Registration: www.zebra.
About This Document Document Conventions Document Conventions The following conventions are used throughout this document to convey certain information: Alternate Color (online only) Cross-references contain links to other sections in this guide. If you are viewing this guide online, click the blue text to jump to its location. Command Line Examples All command line examples appear in Courier New font.
About This Document Document Conventions Illustration Instructions Used when an illustration contains either information about a dialog box or step(s) to accomplish in a dialog box. One illustration instruction identifies a section of the dialog box and the other shows steps to follow. 1 2 1 2 P1043301-002 Set Permanent text-box. a. In the Set Permanent text-box, type in the print server’s IP address. b. When you are finished, click OK.
About This Document Related Documents Related Documents The following documents might be helpful references: • Programming Guide for ZPL II, ZBI 2, Set-Get-Do, Mirror, and WML • ZebraNet Bridge Enterprise User Guide • ZebraNet Connectivity Solutions User and Reference Guides CD • EPL Programming Guide 02/28/2012 P1043301-002 13
About This Document Related Documents Notes • ___________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ _____
1 Introduction This chapter provides a high-level overview of Zebra’s wired and wireless print servers, installation types, standard network configurations, and how to work with the print servers. Contents Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Browser Support . . . . . . . . . . . .
Introduction Overview Overview The print server is an optional factory- or field-installed device that connects the network and your ZebraLink-enabled printer. The print server provides you with a web browser as a user interface for printer and print server settings. If you use the ZebraNet Bridge, you can easily access the specialized features of a ZebraLink-enabled printer. For details, see the ZebraNet Bridge Enterprise User Guide.
Introduction Support Supported Wireless Radio Cards Note • This section applies only to the ZebraNet Wireless Print Server and the ZebraNet Wireless Plus Print Server. All other Zebranet wireless print servers have a built-in radio. A supported third-party PCMCIA, Compact Flash™, or CardBus wireless radio card is required for the printer to connect to the WLAN. After the wireless option board is installed in the printer, the wireless radio card inserts into a slot on this board.
Introduction Support Cisco® Systems All Aironet® cards must have card firmware version 5.60.21 or later. • 802.11g Aironet CB21AG CardBus wireless radio card (for the Wireless Plus Print Sever only) • 802.11b Aironet AIR-PCMC340 • 802.11b Aironet AIR-PCMC341 • 802.11b Aironet AIR-PCMC342 • 802.11b Aironet PCMC350 • 802.11b Aironet PCMC351 • 802.11b Aironet PCMC352 Supported Security Types Your WLAN can use any of a number of different types of security and encryption, or it can use none at all.
Introduction Support ZebraNet Wireless Plus Print Server Table 1 lists the security types that are supported by the Wireless Plus Print Server. Support varies by the card manufacturer and the card type. Select a wireless radio card that is supported by your wireless print server and that supports the security type being used on your WLAN.
Introduction Support ZebraNet Internal Wireless Plus Print Server, ZebraNet b/g Print Server, and ZebraNet n Print Server Table 2 lists the security types that are supported by the Internal Wireless Plus Print Server, the b/g Print Server, and the n Print Server.
Introduction Support ZebraNet Wireless Print Server Table 3 lists the security types that are supported by the Wireless Print Server. Support varies by the card manufacturer and the card type. Select a wireless radio card that is supported by your wireless print server and that supports the security type being used on your WLAN. The Wireless Print Server does not support the Cisco CB21 radio card.
Introduction Printer Requirements Printer Requirements Hardware — Wired Print Servers Table 4 indicates which printers are compatible with wired print server options.
Introduction Printer Requirements Hardware — Wireless Print Servers Table 5 indicates which printers are compatible with wireless print server options.
Introduction Printer Requirements Memory Requirements PCMCIA and Compact Flash Memory Cards PCMCIA memory or Compact Flash memory cards will not work and are not supported on the Wireless Plus Print Server. The Internal Wireless Plus Print Server and the b/g Print Server do not include a slot for these card types. Wireless Card Socket Option The ZebraNet wireless print server options replace the Wireless Card Socket Option (WCSO) in 105SL printers with a serial number of 6400357 or greater.
Introduction Printer Requirements Firmware — 10/100 Print Server The S4M printers and all external print servers are available with several versions of print server firmware. PAX4, 105SL, XiIIIPlus printers will use print server firmware version 1.01.x. To determine the proper firmware version, first determine your hardware version. To locate your hardware version, perform the following: 1.
Introduction Printer Requirements Figure 1 • External 10/100 Print Server Sample Compliance Label 2 1 Tested to Comply With FCC Standards FOR HOME, OFFICE, COMMERCIAL, OR INDUSTRIAL USE This Class B digital apparatus complies with Canadian ICES-003 V2 UID # PN XXXXX SN YYYYYYY 1 2 EN: ZZ:ZZ:ZZ:ZZ:ZZ:ZZ Sample Compliance label Location of hardware version Figure 2 • Internal 10/100 Print Server Sample Compliance Label 2 SN YYYYYYY V2 1 2 P1043301-002 EN: ZZ:ZZ:ZZ:ZZ:ZZ:ZZ 1 Sample Complia
Introduction Printer Requirements Firmware — Wireless After a wireless option board is installed, your printer must be running a supported firmware version to access the features in this manual. Table 7 shows the minimum firmware version required. You may download the latest firmware appropriate for your printer to access the latest encryption features. Go to http://www.zebra.com/firmware for firmware download options.
Introduction Compatibility Compatibility This section identifies the various components that are compatible with all print servers. Software IBM®: Tivoli® v7.1.3, HP®: Web JetAdmin™ v7.0, OpenView™ v6.4, and any SNMP management application via Zebra Management Information Base (MIB) all work with both the wired and wireless print servers.
Introduction Specifications Internal ZebraNet 10/100 Print Server Specifications General Specifications Network Connection Ethernet 10BaseT and 100BaseT UTP RJ-45 connection Half and Full Duplex Communications User Interface A single (two element) LED activity indicator: • bi-color display of operational status (solid green or solid amber) • bi-color display of speed and network activity (flashing green or flashing amber) Height (external dimensions) 0.5 in. 13.4 mm Width (external dimensions) 2.
Introduction Specifications Wireless Print Server Specifications General Specifications Network Connection All Wireless Print Servers • • • • IEEE 802.11b/g Data Rates up to 54 Mb per second Wireless Medium DSSS and OFDM Frequency Band: 2.4 GHz n Print Server • • • • IEEE 802.11a/b/g/n Data Rates up to150 Mbps Wireless Medium DSSS and OFDM Frequency Band: 2.
2 Installation This chapter provides information on how to install the Zebra’s wired and wireless print servers. Contents External ZebraNet 10/100 Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Illustration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation External ZebraNet 10/100 Print Server External ZebraNet 10/100 Print Server This section provides you with an illustration of the external ZebraNet 10/100 Print Server and the steps required for its installation. For a list of compatible printers, see Hardware — Wired Print Servers on page 22. Before You Begin Important • In order to take advantage of all features described in this manual, you must download firmware X.14 or later. Note • Not all printers support firmware X.14 or later.
Installation External ZebraNet 10/100 Print Server Illustration Figure 3 shows an external ZebraNet 10/100 Print Server. When necessary, refer back to this illustration during the installation steps. Figure 3 • External ZebraNet 10/100 Print Server 1 2 5 4 1 2 3 4 5 3 Parallel connector Network status LED Status LED Test button Ethernet connector For more details on status indicators, see External ZebraNet 10/100 Print Server Network Status and Status Indicators on page 130.
Installation External ZebraNet 10/100 Print Server Installation Instructions To install an external ZebraNet 10/100 Print Server, complete these steps: 1. Turn off (O) the printer. 2. On the back of the printer, connect the external ZebraNet 10/100 Print Server device to the parallel port. Figure 4 shows the location and provides an enlarged illustration of the parallel port. Figure 4 • Rear of 105SL Printer Printer Back Parallel Port Connector 3. Secure the wire locks. 4.
Installation Internal ZebraNet 10/100 Print Server Internal ZebraNet 10/100 Print Server To install an internal ZebraNet 10/100 Print Server, see the installation instructions on the Connectivity Solutions CD. Wireless Print Servers To install a wireless print server, see the installation instructions on the Connectivity Solutions CD. Install a Radio Card in a Wireless Print Server Note • This section applies only to the ZebraNet Wireless Print Server and the ZebraNet Wireless Plus Print Server.
Installation Install a Radio Card in a Wireless Print Server 3. Position the notch on the wireless radio card on the top, leading edge. Insert the wireless radio card into the wireless option card slot on the back of the printer until the card-eject button pops out. 4 2 3 1 1 2 3 4 Wireless radio card Notch Wireless option card slot on back of printer Card-eject button 4. Place the RF card cover over the wireless radio card, and secure it with a small screw.
Installation Install a Radio Card in a Wireless Print Server Compact Flash Wireless Radio Card This section applies to Compact Flash wireless radio cards, which require an adapter before they can be used in the wireless option card slot. To install a Compact Flash wireless radio card and adapter, complete these steps: 1. If you have not already done so, turn off (O) the printer. 2. Remove and discard the metal cover that was shipped in place over the wireless option slot on the back of the printer. 3.
Installation Install a Radio Card in a Wireless Print Server 5. Place the RF card cover over the wireless radio card, and secure it with a small screw. Note • The S4M, ZM400, ZM600, RZ400, and RZ600 printers do not use the RF card cover. 3 2 1 1 2 3 Clear plastic RF card cover (not used on all printers) Screw Compact Flash wireless radio card and adapter 6. Turn on (I) the printer. The printer restarts and uses the wireless radio card to communicate with your WLAN.
3 Getting Started This chapter provides you with information and procedures for working with the most frequently used print server features. Contents Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Default User ID and Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printing a Configuration Label — External ZebraNet 10/100 Print Server . . . . . . . . . . . .
Getting Started Contents (Continued) Checking Print Server Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Using ZebraNet Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Using WebView . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Enabling Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
