User's Manual

12
EZ320 User Guide
When the battery is first installed, the printer power and
charge indicators should indicate the battery is not fully
charged (see “Charging the Battery” below and “Operator
Controls”).
You must charge the battery fully before using the printer for the rst
time.
Charging the Battery
Preparing the Power Supply
Before charging the battery for the first time, you must pre-
pare the Power Supply. Refer to Figure 4 below:
Figure 4: Preparing the Power Supply
continued
1. Remove the power sup-
ply from its box. Remove
and discard the shipping
ring from the mains recep-
tacle cavity.
Shipping Ring
Remove and discard
2. Verify that the mains adapter
shipped with your Printer is the correct
one for your region.
Mains Adapter
3. The mains adapter will be
pre-installed into the Power
Supply by hooking the top
edge into the mains recep-
tacle cavity, and rotating it
until it snaps into place.
China/Taiwan-220 VAC
