Icon
Description
Unknown
Indicates a device type not known to MeshTray.
Subscriber Device (SD)
The Computer icon represents a Subscriber Device using a MEA Wireless
Modem Card in the network.
Wireless Router
The Arrow icon represents a Wireless Router (WR), or Mesh Wireless
Router (MWR) in the MEA network. The WR is an infrastructure device
dedicated to routing data.
IAP
The Globe icon represents an Intelligent Access Point (IAP) in the MEA
network. A MEA Intelligent Access Point is an infrastructure device that
allows access to the wired network.
MeshTray Security Tab
The Security tab is used to set the IAP and Peer Authentication passwords to gain access to the
network.
Figure 4-11 MeshTray Security Tab
Require Authentication to IAP Connections
When the Require Authentication to IAP Connections checkbox option is unchecked, it allows
authentication of any device currently being monitored and authentication of devices added to the
