User's Manual

MOTOMESH 1.2 Wireless Modem Card Users Guide
6881011Y52-D January 2007
4-11
3
Right-click on the Local Area Connection corresponding to the Wireless Modem Card and select the
Properties button.
Figure 4-8 Local Area Connection Properties Dialog Box
4 Highlight Internet Protocol (TCP/IP) in the Components dialog box as shown in Figure 4-8.
5 Click on the Properties button.
6 Click on the Advanced button.
7 Click on the DNS tab
8 Click on the DNS Add button.
9 Enter the DNS Server IP Address provided by the Network Administrator and then click the Add button.
10 Click on the OK button to close the Advanced TCP/IP Settings dialog box.
11 Click on the OK button to close the Internet Protocol (TCP/IP) Properties dialog box.
12 Click on the OK button to close the Local Area Connection Properties dialog box.
This configuration should remain in the Windows XP host.
