User's Manual

Chapter 3: Wireless Modem Card Installation
6881011Y52-D January 2007
3-6
3
The antenna must be attached using the clip and vertically oriented when the laptop is in use as shown in
Figure 3-6.
Figure 3-6 Proper Orientation of Antenna
4
The first time that the card is inserted, a message will be displayed indicating that the PC card has been
found as shown in Figure 3-7
Figure 3-7 Found New Hardware Popup Dialog box
