Installing the WMC6300 and the WMC7300
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
.
The following sections will describe the proper installation and removal of the WMC6300 and the
WMC7300 wireless modem cards.
Installing the Wireless Modem Card
Complete the following procedure to install the WMC6300 and the WMC7300 wireless modem cards.
The same installation procedure applies to both wireless modem card model numbers.
Procedure 3-4 Installing the Wireless Modem Card
1
Locate an available Type II PCMCIA card slot in the computer. If necessary, remove the slot dust cover
from the slot.
2
To insure the correct orientation, insert the Wireless Modem Card into the computer’s PCMCIA card
slot with the label side up as shown in Figure 3-5.
Never force the card into the slot.
Figure 3-5 Installing the Wireless Modem Card
Label must
be facing up
