2.13.4 Cleaning the Charging Cradle
The following materials are required to clean the charging cradle:
• Alcohol wipes
• Cotton tipped applicators
• Can of compressed air
Cleaning frequency is discretionary in respect to the environments the charger and the badges are deployed. They may be
cleaned as frequently as required.
2.13.4.1 Cleaning the Badge Contacts
To clean the contacts on a badge before inserting into the charging cradle:
1. Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
2. Rub the cotton portion of the cotton tipped applicator back-and-forth across the contacts. Do not leave any cotton residue
on the contacts (repeat at least three times).
3. Use a dry cotton tipped applicator to clean any moisture or residue remaining on the contacts.
4. Spray compressed air on the contact area by pointing the nozzle about ½ inch away from the surface.
5. Inspect the area for any grease or dirt, repeat this process if required.
2.13.4.2 Cleaning the Cradle Connectors
To clean the connectors within the cradle:
1. Remove DC power cable from the cradle.
2. Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
3. Rub the cotton portion of the applicator along the connector pins. Slowly move the applicator back-and-forth on the
connector to the other. Do not leave any cotton residue on the connector. All sides of the connector should also be rubbed
with the cotton tipped applicator.
4. Spray compressed air in the connector area by pointing the tube/nozzle about ½ inch away from the surface.
5. Ensure there is no lint left by the cotton tipped applicator, remove any lint if found.
6. If grease or other dirt can be found on other areas of the cradle, use a lint free cloth and alcohol to remove.
7. Allow at least 10 to 30 minutes (depending on ambient temperature and humidity) for the alcohol to air dry before applying
power to cradle. If the temperature is low and the humidity is high, a longer drying time is required. Warm temperatures
and dry humidity require less drying time.
add the following: When using sodium hypochlorite (bleach) based
products to clean the product, always follows the manufacturers
recommended instructions regarding the use of gloves during
application and to remove the residue afterwards with a damp cloth
to avoid prolonged skin contact while handling the scanner. Please
note that due to the powerful oxidizing nature of sodium
hypochlorite the metal surfaces on the product are prone to
oxidation (corrosion) when exposed to this disinfectant in the liquid
form and should be removed promptly after cleaning with a damp
cloth.
