The charger's primary function is providing 5Vdc at 900 mA to each badge holder re-charge badge batteries. The charger holds
badges when not in use. When badges are in the charger, they begin to charge using the 5Vdc supplied in the charger base. If
there is sufficient charge detected, the badge uses the charger as a holder (without charging).
While in the charger, the badge could conduct a software or configuration update if required and a status update.
Specification Value
Charger Capacity 1 - 10 badges simultaneously
Voltage 5Vdc +/- 5%
Current Each Badge requires 900 mA during charging, total 5Vdc power is 10 Amps
Power Consumption 50-60 Watts
Power Supply External 12 Vdc, 5 Amps max, 60 watts total, enclosed power supply
Power Cord AC power cord connecting external power supply to AC power
Power Supply Connector Barrel connector (2.5mm outside diameter). The plastic enclosure has built-in strain relief
to prevent accidental disconnects.
Power Indicator All Badges within the charger platform have LEDs indicating charging state
Temperature 0 to 40 degrees C (operating), -40 to 70 degrees C (storage)
Humidity 5 to 95% RH (operating) 85% RH (storage)
Altitude 8,000 ft @ 28 degrees C (operating), 30,000 ft @ 12 degrees C (storage)
