Figure 2-24 GE-MB1000-01-ACC Beacon Accessory
2. Once adhered to the beacon accessory, it can be attached to other items using a lanyard or zip tie placed through the slot
in the surfboard.
2.8.3 GE-MB1000-01-WR Operating Modes
Refer to the following for operating modes for GE-MB1000-01-WR asset beacon operating modes:
NOTE: Once adhered to a surface, its very difficult to remove. The beacon’s adhesive
pads will need to be replaced if it is moved to a new location. The part number for
replacement tape is GE-MB1000-TAPE.
Mode Definition
Sleep The beacon is not transmitting or accepting client connections.
Configuration The beacon accepts connections from clients. Clients can configure the device when
connected.
Broadcast The beacon is transmitting packets that conform to one of the supported beacon formats
(iBeacon, MPact, Battery Save and SecureCast).
