Installation Guide

MPact Location & Analytics Hardware Installation Guide
MN-002947-01 9
There is one style of bracket mount included with the Indoor Style Beacon: Part number - MPACT-MB2000-01-WR.
Figure 2-7 Metal Beacon Wall Mount Bracket: MPACT-MB2000-01-WR
2. Activate one or more MPACT-MB2000-01-WR beacons by pulling the mylar strip out from inside the beacon housing.
Phillips head screw driver for mounting the bracket (metal brackets only) to a wall
Figure 2-8 Indoor Style Beacon - MPACT-MB2000-01-WR
NOTE: Ensure the beacon is positioned correctly, Once the beacon is mounted on the
bracket it will be difficult to remove.
CAUTION: After pulling off the last mylar strip, you have 20 seconds to associate the
beacon in either offline or online mode using the Toolbox application.
