Installation Guide

BEACON HARDWARE SPECIFICATIONS AND
INSTALLATION
MN-002947-01 3
The following setup processes must be completed as a prerequisite to installing beacon hardware:
• MPact Server Installation and Setup - see the MPact Location & Analytics Deployment Guide
• MPact Toolbox and Beacon Installation - see the MPact Toolbox User Guides
The guides are available at www.zebra.com/support.
Lozier® Shelves
Beacon brackets for the MPACT-T1B20-000-WR and MPACT-T1B10-000-WR are used with the following Lozier products:
• TL Shelf
•DL Shelf
•HL Shelf
• Standard Base Deck
2.1 MB1000 Beacon Part Number: MPACT-T1B20-000-WR
As a prerequisite, the following hardware items are required to mount the tie-wrap style beacon housing to a pole or similar
structure:
• Beacon (tie-wrap style housing), part number - MPACT-T1B20-000-WR. (When ordering, use part number: 
MPACT-T1B20-250-WR (box of 25).
• Plastic tie wraps for attaching each beacon housing to the shelf
