User's Manual

© 2014 Motorola Solutions, Inc. All Rights Reserved.
February 12, 2014
80073681.A
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the property of their respective owners..
1. Product Description
Easily installable expansion modules for the WORKABOUT PRO 4 allow you to customise this hand-held
to meet your specific mobile computing requirements. This chapter outlines how to install the RFID
Module HF/LF.
The RFID MODULE HF-KR3-2S (WA9905) or RFID MODULE LF-ID1 (WA9906) kits are
composed of 7 parts:
A. PCB ASSY MODULE HF-KR3-2S or PCB ASSY MODULE LF-ID1
B. PLASTIC MULTIPURPOSE ENDCAP
C. RUBBER PCB GUIDE
D. STOPPER BRACKET
E. USB CABLE
F. LABEL CE/FCC/IC FOR WORKABOUTPRO4
G. INSTRUCTION SHEET WAP4 HF/LF RFID MODULE
A B
C
D
E
G
F
