User manual

VER. 002_12.12.2008
EXAMPLE OF INSTALLATION
CONNECTINGMOUNTING
FUNCTIONING
The timer is ready to work just right
after its appropriate connecting. The light
will be ON for the preset ON-time after
the timer is triggered by means of a single
pole push button. When the preset time
is over, the light will be OFF automatical-
ly until the timer is triggered once again.
The staircase timer may be connected
either to three-conductor or four-con-
ductor wiring. Check carefully if trigger
and load circuits have been connected
correctly. The timer may be damaged if
connected inappropriately. In case of the
counter-interlock circuit lack the light is
continuously ON when the trigger push
button is blocked.
1. Disconnect the electric network by
means of an appropriate cut-off, cur-
rent limiting circuit-breaker or separa-
tor.
2. Check if there is no any voltage be-
tween power leads by means of an
appropriate gauge.
3. Place the ASP-02 timer in a junction
box and connect leads accordingly to
electrical diagram.
4. Connect power supply circuit.
5. Adjust the light ON-time required by
means of the potentiometer.
DIMENSIONS
INNER DIAGRAM
TIME COURSE PRODUCT FAMILY
RELAY CAPACITY
The ASP-02 is a member of the ASx
staircase timer family.
375 W 180 W
90 W 150 W
NL
IN
t
L/N
b
r
o
w
n
r
e
d
b
l
a
c
k
b
l
u
e
b
r
o
w
n
r
e
d
b
l
a
c
k
b
l
u
e
Device symbol
Type of casing:
M – monomodular
N – surface mounting
H – hermetical
P – for junction box mounting
Device version:
01 – three - or four-conductor
wiring
02 – anti-lock system
10 – dimmer function
Version 24 V AC/DC
for ASM-02 available
