User's Manual

. Primary to Secondary : 500VDC 100
. Primary to FG : 500VDC 100
DATE: 2005. 1. 17
ZALMAN SPECIFICATION PAGE: 6/9
MODEL NO: TNN350APF-V1 REV.0
Shall be 1.0mA Maximum at 220VAC Input
On
2.4.11. LEAKAGE CURRENT(IEC950)
. The Maximum Leakage Current Following The Frame / AC Sine Conductor
2.4.10. INSULATION VOLTAGE WITHSTAND
2.4.6. MEAN TIME BETWEEN FAILURES
. Operating Time 50,000HR at 25.
2.4.7. This power supply shall comply with the followings.
. CSA C22.2 NO220 & CSA Bulletin 1402C, Level3
Off
Control Signal
Logic " Low"
Logic " High"
Output Status
2.4.9. POWER SWITCH On/Off TEST
2.4.4 DC INPUT PROTECTION
. VDE 0806, EN60950 A3
. IEC950
2.4.5. BURN-IN
Primary lot is output full load at 55 24HR
. UL1950
. Use proper fuse for DC input over current protection.
2.4.8. EMI
. VDE 0871/6.78 Class B
. FCC Part 15 Sub Part J, Class B
