Component and System (non input) Specications
Hardware
System System Feature Specication
Display/LEDs backlit graphic LCD (320X240)
with timer
readings updated 2 times a
second
diagnostic troubleshooting
LEDs
Outputs 8 on-board relays 240VAC@ 5AMPs switching
capacity; 110VAC@10AMPS;
type: SPDT
Timer Systems 4 timers 10 daily events per timer system
4 feed timers includes sensor & FCR control
Power: ere are two 5X00 versions available. e DC version can only be powered by
DC power. e AC version can be powered by AC or DC power.
Power for DC
Version:
external 12VDC power source 9-16.5VDC; 800 mA
Power for AC
Version:
internal AC switching power
supply
100-240VAC; 50-60Hz; 300 mA
Both AC and DC
versions:
lithium battery (for real time
clock)
2032 lithium ion
Electronics ARM7 embedded microproces-
sor
DSP (digital signal processing) Digital processing of 5X00
information ensures accurate and
repeatable readings.
Introduction
Firmware
Feature Specication
Flash Memory Firmware eld upgradable with
local PC connection
Data Logging non-volatile data log memory
storage of 4750 records
sensor log (2000 records)
event log (1250 records)
calibration log (500 records)
Conguration
log (1000 records)
Security password protection
Data ltering reads 2-3 times per second; read-
ings are averaged
Communication
Feature Specication
RS232 up to 100  (30m)
OR
Optional serial to ethernet
device
remote TCP/IP PC access and/or
email alarming
Instrument to Instrument Networking
Feature Specication
Network 2 to 32 isolated 5X00
and/or 5200A instruments
RS485 up to 4000  (1220m)
entire network distance
AquaManager
Feature Other PC Requirements
Runs on Windows 2000/XP/
Vista/Windows 7 operating
systems 32-bit and 64-bit
PC capable of running Windows
2000
VGA display card
CD-ROM Drive
Total RAM Installed 16
Megs or greater
100 MB free hard-disk space
