6. Press for feed timer relay to energize for congured run test
time. Countdown of relay “on” time is displayed.
7. When run time expires, the relay de-energizes. Enter the amount of
food dispensed at the Measured Weight screen.
8. Press
to save settings and return to Run Screen.
Notes:
- Since feeders and food size vary, run several calibrations and enter the aver-
age weight at the last calibration. If feeder or feed type is changed, recalibrate
the feeder.
- If no test/calibration has been performed or if the results have not been saved,
the 5X00 will be unable to perform any feeding(s) because there will be no
reference to determine the rate at which feeding(s) will occur.
- Stored calibration data is available from the AquaManager program.
- If feed timer units change, the feeder must be recalibrated.
- If an incorrect value is entered and saved, another calibration must be per-
formed.
- Disable feed timer system when performing feed timer calibration, de-ener-
gizing any active feed timer relay.
- Aer calibration is complete, press
to Run Screen. e Feed timer
system resets based on new calibration conguration.
- Feed Timer calibration cannot be done using AquaManager.
AquaManager and the Timer Menu
Most Timer menus can be congured using AquaManager. Aer polling the 5X00
node, use “Systems Management” to view and upload 5X00 congurations. Select
the Feed Smart
tm
and Timers tabs to view and change conguration.
Notes
- Always manually poll the 5X00 aer uploading conguration changes and
verify that the uploaded information is retained. When conguration changes
are uploaded using AquaManager at the same time conguration changes are
being made by a user in the menus at the 5X00, AquaManager uploads may
not be saved depending on the timing of keystrokes at the 5X00.
