Input System Specications
Aux Systems
ere are 6 Aux input systems that allow digital or analog (0-
1.0VDC, 0-5.0VDC, or 4-20mA) conguration. In addition, four
of the Aux systems can be congured as temperature systems see
Temperature Systems Specs - page 15.
Aux System Type Digital Analog
Range dry contact open/close 0 -1.0 VDC, 0-5.0 VDC, or 4-20mA
Accuracy n/a 0-1.0VDC: ± 3% ± 10 mV
0-5.0VDC: ± 3% ±15 mV
4-20 mA: ± 3% ±100A
Resolution n/a user selectable (0), (0 .0), or (0.00)
DO Systems
ere are up to 4 independent DO systems. Each DO system has
2 control ranges, 2 control ranges, and high and low alarming.
Sensor Type
5400
Polarographic (mA) Galvanic (mV)
Membrane Type Teon (TE), 2 mil (gray)
Polyethylene (PE), 2 mil (blue)
Teon (TE), 2 mil (gray)
Range 0 to 500% air saturation
0 to 60 mg/L
0 to 500% air saturation
0 to 60 mg/L
Accuracy ±2% or ± 0.2 mg/L, whichever is
greater for 0-200%
±6% of reading for 200-500%
±2% or ± 0.2 mg/L, whichever
is greater for 0-200%
±6% of reading for 200-500%
Resolution 0.1% (0.0-99.9%); 1% (> 99.9)
0.01 mg/L (0-10 mg/L); 0.1 mg/L
(10-60 mg/L)
0.1% (0.0-99.9%); 1% (> 99.9)
0.01 mg/L (0-10 mg/L); 0.1
mg/L (10-60 mg/L)
Response Time 95% of reading in 17 seconds for
2.0 mil PE membrane;
95% of reading in 36 seconds for
2.0 mil Teon membrane.
Allow approximately 10-15 min-
utes aer 5X00 is powered on, or
aer the DO sensor is serviced,
for the polarographic sensor to
stabilize.
95% of reading in 36 seconds
for 2.0 mil Teon membrane.
Cable lengths 4, 10, 20 m (special order up to
100m)
4, 10, 20 m (special order up to
100m)
Introduction
Flow require-
ments
minimum ow rate of 3 inches
per second or 7.62 cm/second for
2.0 mil PE membrane; 6 inches
per second or 15.24 cm/second
for 2.0 mil Teon membrane
6 inches per second or 15.24
cm/second for 2.0 mil Teon
membrane
Other manual salinity compensation for
DO mg/L readings
manual salinity compensation
for DO mg/L readings
Sensor Type
5500D-01, 5500D-02,
5500D-04
Optical Dissolved Oxygen (dynamic luminescence quenching
lifetime detection)
Dimensions 19 cm length (7.5 in); 2.4 cm diameter (0.95 in)
Membrane Type Sensor Cap includes calibration coecients
Range 0-500% air saturation
0 to 50 mg/L
Accuracy ±0.2°C
Salinity Input Range 0-50 ppt
Storage Temperature -20 to 70°C
Operating Tempera-
ture
-5 to 70°C
Response Time 90% in 25 seconds; 95% in 45 seconds
Cable lengths 1- 4- 10- 20- 30- 40- 50- 60- and 100-m;
(3.3, 13.1, 32.8, 65.6, 98, 131, 164, 197 and 328 )
Flow requirements None
Temperature
Systems
ere are 4 independent temperature systems. Auxiliary inputs
3, 4, 5, & 6 can be congured as temperature systems. Each tem-
perature system has 1 control range, 1 control  range, and high
and low alarming. Temperature systems can be congured as the
temperature source for DO measurements on a 5400 or as stand
alone systems on either 5400 or 5500 instruments..
Sensor type 10,000 ohm @ 25°C thermistor
Range 0-45°C; 32-113°F
Accuracy ± 0.2°C
Resolution 0.1°C
