Figure 1.1
Preview of User Manual
is manual includes information on installing, conguring, operating, and main-
taining a 5X00 system. YSI 5400, 5500D-01, 5500D-02 and 5500D-04 instruments
have many similarities. erefore “5X00” is used throughout this manual to refer to
YSI 5400, 5500D-01, 5500D-02 and 5500D-04 instruments. 5500D-01, 5500D-02 and
5500D-04 at times are referred to collectively as 5500D instruments. Instructions,
information and features specic to either YSI 5400 or YSI 5500D instruments will
be referenced by using 5400 or 5500 in the le margin next to specic information. .
Read Chapter 2 “Safety Information” starting on page 20 before installing or
conguring a 5X00 system.
Chapter 3 “Installation” starting on page 26 provides information on how to
install the 5X00, 5X00 components, and peripheral devices. Only qualied people
should install a 5X00 system. Do not attempt to install or congure this device if
you are not qualied to do so. If information is not clear, DO NOT PROCEED until
clarication can be obtained. All wiring involving connections to main power must
be performed by a qualied licensed electrician and must conform to all locally
applicable electrical codes.
Introduction
Chapter 4 “Conguring 5X00 Systems” starting on page 74 provides information
on conguring 5X00 instruments.
Chapter 5 “AquaManager” starting on page 175 provides general information
regarding the PC soware program. e AquaManager program includes an exten-
sive on-line help system which contains detailed information that is not provided
in this manual.
is icon is used throughout the manual to indicate helpful information for Aqua-
Manager users.
Chapter 6 “Maintenance” starting on page 188 provides information on maintaining
the 5X00 system including monitor and sensor service.
“Notes” at the end of each manual section provide additional information to help
clarify certain 5X00 operations and features.
Appendices include information on Unpacking & Inspection, Troubleshooting,
Menu Maps, Declaration of Conformity, Parts and Accessories, SMS Messaging.
Warranty, Contact Us, Alpha “A” Curve and Recycling information.
An index is provided starting on page 240.
Product Specications
To ensure accurate and reliable performance, operate the 5X00 system according
to the specications provided in the following tables. Damage and/or incorrect
operation could result if these specications are not followed.
Product specications are subject to change without notice. Visit www.ysi.com to
view the most recent product specications.
Environmental Specications
Environmental Category Operating Range
Temperature -15 to 70C (5 to 158F)
Enclosure Rating NEMA 4X (direct exposure to outside conditions) IP65
Compression Fitting Rating IP 68/NEMA 6 (liquid tight)
Electrical Safety IEC compliant*
Other RoHS compliant
See Appendix 4 Declaration of Conformity - page 228.
