5. Congure PC com port number (1-8) in Flash Programmer.
Notes:
- Use only a Tripp-Lite Keyspan USB-Serial Adapter, model USA-19HS YSI
p/n
773.
- When using USB-Serial Adapter, verify that the port number assigned dur-
ing driver installation is the same port congured when using AquaManager
Flash Programmer.
6. AquaManager Program Folder includes the latest version of instru-
ment rmware. e lastest rmware is stored as an .mdb le in the PC
Program Files>AquaManager>Firmware. At AquaManager, Firmware
Updater>File>Load Firmware Database. Locate and load this le into
the Firmware Updater.
7. Le click
button.
window opens.
8. Select “Yes” and the following screens will appear.
Conguring the 5X00
On instrument On PC
YSI 5200A/5400/5500 Bootstrap Loader screen Flash Programmer uploading rmware into
5X00
Note:
- If the YSI 5200A/5400 Bootstrap Loader screen does not appear at the instru-
ment aer above steps manually place 5X00 in downloader at Menus → System
→ Downloader. Close and reopen AquaManager. Reopen Flash Programmer
and repeat steps starting at 6.
- Power cycle to exit downloader and return to run screen. Do not power
cycle during an active upload.
- If aer manually placing the 5X00 into downloader and the Flash Program-
mer utility still does not upload rmware see Force Downloader - page 123.
9. e 5X00 will reboot (power cycle) when rmware upload is complete.
10. Select “ok” when this window appears
11. Close Flash Programmer.
12. Verify version information to conrm downloaded code:
Menus → System → Version
13. If applicable, disable Force Serial Port conguration.
