Data Logging
Menus → System →Data Logging
e 5X00 saves information in calibration, sensor, and event logs. Press
at the Run Screen to view the 25 most recent records for each log. e 5X00 sensor
log stores 2000 records. e calibration log can store 500 records. And the event
log stores 1250 records. Once a 5X00 log is full, it will begin overwriting the oldest
records with new records (data wrapping).
Notes:
- Use AquaManager to store and analyze 5X00 logs. To avoid gaps in data, use
polling intervals based on the user dened data logging conguration. Set
the data log interval so that analyzing the data is meaningful.
- AquaManager users can view Conguration events in the Conguration log.
Conguration events are created when certain 5X00 conguration changes are
made. e conguration log is not accessible at the 5X00. See AquaManager
Online Help for additional information.
Data Logging
Menus → System →Data Logging→Data Logging
e 5X00 sensor log stores records for sensors and aux systems. Sensor logs are time
and date stamped based on the user congured logging interval (1-255 seconds/
minutes/hours).
Conguring the 5X00
1. Enter Data Logging menu
Menus → System →Data Logging→Data Logging
2.
Use
▲ ▼
to scroll and highlight submenus.
3.
Press

to select.
4. Enable and congure submenus.
5. Press
to save setting and return to Run Screen.
Press
to view the 25 most recent sensor logs
Notes:
- Aux digital “closed” is logged as Aux 0.00. Aux digital “open” is logged as
Aux 1.00.
- e 5X00 sensor log records 0.00 resolution for aux analog inputs regardless
of the selected display format.
- DO values are stored in mg/l & %Sat regardless of selected display format.
- Sensor logs record the default system name and not the user congured
system name.
- Aux temperature values are not accessible at the 5X00. Temperature values
can only be obtained using AquaManager. Values will be shown in the Aqua-
Manager data log in °C regardless of the selected display format.
- Temperature values are only available and stored for temperature systems as-
signed to a DO system. ese values are not available at the 5400. e values
can only be viewed with AquaManager.
- Temperature values are available for either a ODO temperature sensor or a
stand alone aux temperature systems. ese values are not available at the
5500. e values can only be viewed with AquaManager.
- Changes to the data logging interval take eect aer the expiration of the
interval being changed. Example - if the interval is changed from one hour to
one minute, one minute logging will begin aer the expiration of the current
one hour interval. Power cycle the 5X00 to make a change to the data logging
interval occur immediately.
- Menu congurations are saved to the system by pressing
to return
to the Run Screen and not when the change is made in the menu. Excep-
tion - Date and time and clear data logs are updated immediately to the
system, not when
is pressed.
- e sensor log contains values for all sensor and aux systems regardless if the
system is disabled.
- 5X00 sensor log values for disabled systems and systems without sensors are
not valid.
