Subnet Mask
Menus → System → Communications → Ethernet → Subnet Mask
A Subnet mask address can only be congured when DHCP is disabled. e subnet
mask number helps to dene the relationship between the host (computers, rout-
ers, switches, etc.) and the rest of the network. Consult the network administrator
when conguring this menu.
Notes:
- When DHCP is enabled, the Subnet Mask address is not updated at the Subnet
Mask menu.
- AquaManager users should program the Subnet mask either by force serial
port using AquaManager or locally at the 5X00. Poll node using RS232 com-
munication . Next upload conguration information including: static IP, port,
subnet, and gateway addresses.
- Numbers between 0-255 are valid for each of the four (4) Subnet Mask IP
Address elds.
Gateway
Menus → System → Communications → Ethernet → Gateway
e Gateway address can only be congured when DHCP is disabled. A gateway IP
refers to a device on a network which sends local network trac to other networks.
Consult the network administrator when conguring this menu.
Notes:
- When DHCP is enabled, the Gateway address is not updated at the Gateway
menu.
- AquaManager users should program the Gateway address either by force
serial port using AquaManager or locally at the 5X00. Poll node using RS232
communication . Next upload conguration information including: static IP,
port, subnet, and gateway addresses.
- Numbers between 0-255 are valid for each of the four (4) Gateway IP Ad-
dress elds.
Port
Menus → System → Communications → Ethernet → Port
e default port number for the ethernet module is 10001. Consult the network
administrator when conguring this menu.
Note:
- AquaManager users should program the port number either by force serial
Conguring the 5X00
port using AquaManager or locally at the 5X00. Poll node using RS232 com-
munication . Next upload conguration information including: static IP, port,
subnet, and gateway addresses.
DNS Address
Menus → System → Communications → Ethernet → DNS
Domain Name Service (DNS) refers to the server, or workstation, used to convert
domain names into IP addresses.
Notes:
- With DHCP enabled, the serial to ethernet device will acquire SMTP and DNS
addresses during initialization.
- When DHCP is enabled, the DNS address is not updated at the IP address
menu.
- Numbers between 0-255 are valid for each of the four (4) DNS IP Address elds.
Email Addresses
Menus → System → Communications → Ethernet → Email Address
→ Email Address
→ Email Address
→ CC/Email Address
Up to four email addresses can be congured for 5X00 emails. At a minimum, the
rst email address and the CC/email address must be congured. If the CC/email
address is not congured, 5X00 email alarms will contain no alarm information.
e email ‘from’ address will be the email address entered in the rst Email Ad-
dress menu.
Notes:
- See Send Test Email Msg - page 101 to verify proper conguration of ethernet
menus.
- On a network, both master and slave alarm emails are sent to the congured
email addresses in the master.
- Test the alarm email delivery by creating an alarm condition at the 5X00 and
verify the email(s) is received.
- e CC/Email address must be congured when using 5X00 email alarming.
Specic alarm system information will not be sent if the CC/Email address
menu is not congured with a valid email address.
- Use AquaManager to easily congure email addresses using the PC keyboard.
See AquaManager on line help for additional information.
- If Autopoller is being used for AquaManager email alarming on a TCP/IP
connection, it is strongly recommended that the 5X00 email alarming using
the serial to ethernet device be disabled. When the ethernet device sends
email alarms, all Autopoller SMS communication is suspended. is could
