1. Install serial to ethernet device - page 65.
2. e Ethernet icon
displays at the Run Screen when the serial to
ethernet device is properly installed.
3. Enter Ethernet menu
Menus → System → Communications → Ethernet
4.
Use
▲
and
▼
to scroll and highlight submenus.
5.
Press

to select submenu.
6. Congure submenus as needed.
7. Press
to save conguration and return to Run Screen.
Notes:
- e CC/Email address must be congured when using 5X00 email alarming.
Specic alarm system information will not be sent if the CC/Email address
menu is not congured with a valid email address.
- If Autopoller is being used for AquaManager email alarming on a TCP/IP
connection, it is strongly recommended that the 5X00 email alarming using
the serial to ethernet device be disabled. When the ethernet device sends
email alarms, all Autopoller SMS communication is suspended. is could
potentially delay any AquaManager alarm emails from being sent.
- To disable the serial to ethernet device from sending alarms, clear all four
email addresses from the Communication → Ethernet menus. Clear the email
addresses by using the “Spc” (space) key on the numeric keypad. Save changes
at numeric keypad and press
to save conguration and return to Run
Screen.
Conguring the 5X00
DHCP
Menus → System → Communications → Ethernet → DHCP
Enable DHCP if you are using the serial to ethernet device only for 5X00 email
alarming and not for AquaManager remote TCP/IP access.
Notes:
- When DHCP is enabled, the 5X00 IP address is not updated at the IP address
menu.
- With DHCP enabled, the serial to ethernet device acquires SMTP and DNS
addresses during initialization.
- AquaManager requires a static IP address; therefore, DHCP must be disabled
when using AquaManager. Consult the network administrator to obtain a
static IP address.
- Power cycle the 5X00 if DHCP conguration changes from disabled to en-
abled..
IP Address
Menus → System → Communications → Ethernet → IP Address
e IP address can only be congured when DHCP is disabled.
Notes:
- AquaManager users should program the IP Address either by force serial port
using AquaManager or locally at the 5X00. Poll node using RS232 commu-
nication . Next upload conguration information including: static IP, port,
subnet, and gateway addresses.
- When DHCP is enabled, the IP address is not updated at the IP address
menu.
- Power cycle the 5X00 whenever a new IP address is congured.
- Numbers between 0-255 are valid for each of the four (4) IP Address elds.
