3-16
IM 77C01E01-01E
3.9 Setting the Measured Value Display Pattern
This section explains how to set the measured value display pattern by taking as an example the case
when the number of display patterns is changed to 3 and the display pattern-1 upper display to maximum
demand value, from their respective initial values.
Operation
Operation
3
4
6
7
5
8
9
10
Number of Display Patterns
screen
Current value
VT Ratio screen
2
Display Setting Menu screen
Number of Display Patterns
Setting screen
Number of Display Patterns
Setting screen
Measured Value screen
1
The parameter (VT ratio)
appears.
Press once.
Press once.
The screen changes to the one
for setting the parameter
.
Display Pattern-1 Upper
Display Setting screen
The screen changes to the one
for setting the parameter
.
Display Pattern-1 Upper
Display Setting screen
Number of Display Patterns
screen
The parameter
(number of display patterns)
appears.
Display Pattern-1 Upper
Display screen
The parameter
(display pattern-1 upper display)
appears.
Press twice.
Setpoint
Hold down for at
least 3 seconds.
Using or ,
show .
Using or ,
select the setpoint.
Press once to
blink the setpoint.
Using or ,
select the setpoint.
Press once to
blink the setpoint.
Press once while
the setpoint is blinking.
The setpoint is confirmed and the PR300
returns to the Number of Display
Patterns screen.
Number of display patterns
setting completed.
Press once.
Press once.
Press once while
the setpoint is blinking.
To re-set the parameter:
Press any key other than
while all digits of the
setpoint are blinking.
The PR300 returns to the initial
setting screen.
