User’s Manual PRM Synchronization Tool IM 01R01A20-01E IM 01R01A20-01E 8th Edition
Toc-1 PRM Synchronization Tool IM 01R01A20-01E 8th Edition CONTENTS A Symbol Marks in the User’s Manual........................................................A-1 1 Overview..................................................................................................... 1-1 System Configuration.................................................................................... 1-1 PRM Synchronization Tool activities.............................................................
Toc-2 4 Device Tag Extension Mode..................................................................... 4-1 Outline of PRM/FieldMate synchronization compatibilities........................... 4-1 Preconditions for PRM/FieldMate Synchronization...................................... 4-1 Synchronizing Devices with HART Device Tag Display Format................... 4-2 Synchronizing Devices in STARDOM Upstream Project.............................. 4-3 Appendix............................................
A-1 A Symbol Marks in the User’s Manual The symbol marks appearing in the user’s manual have the following meanings. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices.
1-1 <1 Overview> 1 Overview PRM Synchronization Tool realizes device information exchange between FieldMate and Plant Resource Manager (PRM). The consolidated database management in PRM is provided by utilizing field device information implemented and acquired by FieldMate System Configuration The followings displays sample system configuration PRM Ethernet Control station Data Transfer Firewall FieldMate Field device 010101E.
<1 Overview> 1-2 Device for Tool Supported communication protocol FOUNDATION fieldbus HART BRAIN Devices Devices registered in FieldMate Devices registered in PRM Data for Tool The following data are object of Synchronization Tool Devices data Device details Device status History Memo (AXF Verification date) Documents Parameter sets DTM data TIP AXF Verification data are synchronized, however these are attached in Memo and cannot be viewed in PRM IM 01R01A20-01E 8th Edition : May 31, 2
2-1 <2 Operation Preparation> 2 Operation Preparation This chapter describes the operation preparation before starting PRM Synchronization Tool. Software operation condition PRM R3.02 or later FieldMate R1.03 or later Since the new functionality support on PRM and FieldMate needs to be considered such as new DD Menu for e-EDDL and Device Tag Extension Mode, the compatibility between different versions of PRM and FieldMate is shown as below. PRM R3.01 or earlier and FieldMate R1.
2-2 <2 Operation Preparation> NOTE PRM Synchronization Tool is included in the FieldMate R1.03/R2.01 or later. It will be installed simultaneously. Create a PRM user account with the correct privilege • Create PRM user account. • Apply the Update PRM Synchronization Tool privilege on your PRM user account. SEE ALSO For details, please see: IM 33Y05Q10-11E, Plant Resource Manager Reference.
<2 Operation Preparation> 2-3 Define PRM Server to connect to Use FieldMate’s PRM Setup Tool to specify the PRM Server where FieldMate will connect to. To specify the PRM server set in PRM Setup Tool: 020201E.ai Figure2-1 PRM Setup Tool Start 1. On your desktop, select [Start] > [All Programs] > [YOKOGAWA FieldMate] > [Tools] > [PRM Setup]. This starts PRM Setup Tool. 2. Select a connection type: • Select [Use One PRM Server] to enter one PRM Server.
3-1 <3 PRM Synchronization Tool start> 3 PRM Synchronization Tool start This chapter provides detailed steps on how to use the Restore, Backup, and Synchronize activities. The figure below displays a comprehensive view of the PRM Synchronization Tool process flow.
3-2 <3 PRM Synchronization Tool start> 3-1 Restoring device information from PRM to FieldMate Select the Restore activity to transfer data records from PRM to FieldMate. This enables users to refer to previous data when performing on-site device tuning using FieldMate. To restore device information: 1. On your desktop, select [Start] > [All Programs] > [YOKOGAWA FieldMate] > [Tools] > [PRM Synchronization Tool]. The PRM-Login dialog box appears. 2.
3-3 <3 PRM Synchronization Tool start> 7. Select a PRM Device Navigator option: • [Plant View] to display Plant view in the right pane. • [Network View] to display Network view in the right pane. • [Class View] to display Class view in the right pane. • [Custom View] to display Custom view in the right pane. • [Search] to perform a search. • [Selected Devices] to display selected devices for Restore.
3-4 <3 PRM Synchronization Tool start> 8. In the right pane, click the check boxes corresponding to the devices you want to include in the activity. A check mark appears on the top of the device tag to indicate that the device is selected. Device tags that appear in blue indicate that the device was included in the list of the previous data transfer. Device layout displayed in the right pane is not always identical to the ones in PRM.
3-5 <3 PRM Synchronization Tool start> Handling overwrite messages During the Restore activity, the Overwriting Message dialog box appears when the device information from FieldMate is different from the device information in PRM. This dialog box enables you to select the overwrite rule. Table3-1 Situations that trigger the Overwriting Message PRM Timestamp FieldMate Timestamp Result Same Same None. Newer Older Overwriting Message appears. Older Newer Overwriting Message appears.
3-6 <3 PRM Synchronization Tool start> 3-2 Backing up device information from FieldMate to PRM After performing device tuning using FieldMate, select the Backup activity to transfer device information from FieldMate to PRM. This feature enables FieldMate to make full use of the larger capacity of PRM to store device information. Before proceeding with the activity, you can enable an option to delete selected devices in FieldMate after the data transfer.
3-7 <3 PRM Synchronization Tool start> 7. Select a FieldMate Device Navigator option: • [All] to display all FieldMate devices in the right pane. • [Favorites] to display favorite devices in the right pane. • [Search] to perform a search. • [Selected Devices] to display selected devices for synchronization.
3-8 <3 PRM Synchronization Tool start> 9. Click the [Delete selected devices from FieldMate after Backup Activity] check box if you want to delete the devices in FieldMate after the activity. 10. Click [Start Backup]. The Backup Devices in Progress dialog box appears to display the activity progress. When you start the activity, a dialog box appears to display the activity progress. Click [Show Details] to display the activity details.
3-9 <3 PRM Synchronization Tool start> 3-3 Synchronizing device information between PRM and FieldMate Select the Synchronize activity to update information between FieldMate and PRM based on new records. Newly-imported devices in PRM appear in the Spare folder of Plant view, in the respective protocol folder in Network view, and under the actual class of the device in Class view. Devices that were included in the previous data transfer will remain in the same view and folder.
3-10 <3 PRM Synchronization Tool start> 030306E.ai Figure3-6 8. PRM Synchronization Tool window - Synchronize activity In the right pane, click the check boxes corresponding to the devices you want to include in the synchronization. A check mark appears on the top of the device tag to indicate that the device is selected. TIP 9. • To view selected devices, select [Selected Devices] to view them. This will display all selected devices in the right pane.
3-11 <3 PRM Synchronization Tool start> TIP You can also stop the activity at any point in time. To stop the activity, click [Stop] in the Synchronize Devices in Progress dialog box. When an activity is stopped, the process is halted but the information that was processed before stopping the activity will not be reverted. 11. When the activity is finished, click [Close].
3-4 3-12 <3 PRM Synchronization Tool start> Performing advanced configurations and searching devices PRM Synchronization Tool includes advanced configurations and search options. Performing advanced configurations The Advanced Configurations option appears in the Synchronize and Restore activities. This dialog box allows you to select the data to be included in the data transfer. During the data transfer, device details and device status are automatically included.
3-13 <3 PRM Synchronization Tool start> History History messages can be included in the data transfer. When included, you can specify the history message items you want to include. 030308E.ai Figure3-8 Advance Configuration dialog box - History tab TIP PRM Synchronization Tool can include maintenance alarm messages from PRM but cannot acknowledge or create new messages. To select history messages: 1. Under Data Options, select the [History] check box.
3-14 <3 PRM Synchronization Tool start> Memo You can include a maximum of 1000 memos during data transfer. Both approved and unapproved memos will be transferred from PRM to FieldMate. Memos that are transferred from FieldMate to PRM will be created as unapproved memos. 030309E.ai Figure3-9 Advanced Configurations dialog box - Memo tab To select memo: 1. Under Data Options, select the [Memo] check box. A check mark appears and the options in the Memo tab are enabled.
3-15 <3 PRM Synchronization Tool start> Parameter sets You can configure the parameter set for each selected device. FieldMate can support up to five parameter sets for each device. When this limit is reached, FieldMate will automatically overwrite the oldest parameter set. You can select parameter sets either automatically or manually. In the Synchronize activity, both PRM and FieldMate parameter sets can be manually selected.
3-16 <3 PRM Synchronization Tool start> 4. Click [OK] to apply and save the settings. • Click [Cancel] to revert to the previous configuration settings. • Click [Default] to use the Advanced configurations default settings. SEE ALSO For “Do not Archive key”, please see: “Performing device parameter adjustment” in A6 IM 33Y05Q10-11E, Plant Resource Manager Reference. DTM data The method for selecting DTM data is identical to the method for selecting parameter sets.
<3 PRM Synchronization Tool start> 3-17 Searching for a device The Device Navigator provides a search facility to help you look for devices. 030312E.ai Figure3-12 Search pane To use search: 1. Select [Search] from the Device Navigator. The Search pane appears. 2. In the Search pane, select a category from the [Look In] drop-down list. 3. Select the search criteria from the [Criteria] drop-down list. 4.
4 4-1 <4 Device Tag Extension Mode> Device Tag Extension Mode Outline of PRM/FieldMate synchronization compatibilities Devices with extended device tag are recognized and handled according to HART Device Tag Display Format such as “Tag + Descriptor” or “Descriptor” or “Message” on both PRM and FieldMate sides. On PRM R3.03 or later and FieldMate R2.01.
4-2 <4 Device Tag Extension Mode> Synchronizing Devices with HART Device Tag Display Format The same Device Tag Extension Mode needs to be set on PRM and FieldMate. Even if the user renames the device tag on one side, it is updated to the other side after the synchronization as long as the HART Device Tag Display Format of the device is consistent with the HART Device Tag Display Format on the other side.
<4 Device Tag Extension Mode> 4-3 Synchronizing Devices in STARDOM Upstream Project TIP The followings describes sample case and operation work flow only for STARDOM user. In STARDOM upstream project, the synchronization between PRM and FieldMate works except the project name portion of the extended device tag. Project name is ignored.
App.-1 Appendix References 1. FieldMate Versatile Device Management Wizard (IM 01R01A01-01E).
