Instruction Manual

4-14 Profibus
IM 12A00A01-61E
Solution 2 at Temp. 2 0.101 S/cm R/W 4, 101 float (4)
Solution 2 at Temp. 3 0.141 S/cm R/W 4, 102 float (4)
Solution 2 at Temp. 4 0.182 S/cm R/W 4, 103 float (4)
Solution 2 at Temp. 5 0.223 S/cm R/W 4, 104 float (4)
Solution 3 at Temp. 1 0.086 0~1.999, 0~999MΩ•cm S/cm R/W 4, 105 float (4)
Solution 3 at Temp. 2 0.145 S/cm R/W 4, 106 float (4)
Solution 3 at Temp. 3 0.207 S/cm R/W 4, 107 float (4)
Solution 3 at Temp. 4 0.264 S/cm R/W 4, 108 float (4)
Solution 3 at Temp. 5 0.318 S/cm R/W 4, 109 float (4)
Solution 4 at Temp. 1 0.105 0~1.999, 0~999MΩ•cm S/cm R/W 4, 110 float (4)
Solution 4 at Temp. 2 0.185 S/cm R/W 4, 111 float (4)
Solution 4 at Temp. 3 0.286 S/cm R/W 4, 112 float (4)
Solution 4 at Temp. 4 0.339 S/cm R/W 4, 113 float (4)
Solution 4 at Temp. 5 0.41 S/cm R/W 4, 114 float (4)
Solution 5 at Temp. 1 0.127 0~1.999, 0~999MΩ•cm S/cm R/W 4, 115 float (4)
Solution 5 at Temp. 2 0.223 S/cm R/W 4, 116 float (4)
Solution 5 at Temp. 3 0.319 S/cm R/W 4, 117 float (4)
Solution 5 at Temp. 4 0.408 S/cm R/W 4, 118 float (4)
Solution 5 at Temp. 5 0.495 S/cm R/W 4, 119 float (4)
4-4-3-3. Function Block Parameters ISC202
Parameter Default Alternatives Unit R/W Slot, Index Data Type
(byte,bit) (bytes)
4-4-3-2. Function Block Parameters SC202 (continued)
Parameter Default Alternatives Unit R/W Slot, Index Data Type
(byte,bit) (bytes)
Primary Value Parameters
Primary value Type Conductivity(113) conductivity(113), resistivity(116) R 4, 27 unsigned16 (2)
Measured Value S/cm 4, 28
Status 4, 28
Conductivity sensor type toroidal(147) R/W 4, 42 unsigned16 (2)
Secondary Value Parameters
Value -20~140, 0~280 °C R 4, 36 DS-33 (5)
Status 4, 36
Secondary value unit °C(1001) °C(1001), °F(1002) R/W 4, 37 unsigned16 (2)
Sensor temp comp Automatic(3) auto(3) R 4, 38 unsigned8 (1)
Sensor temp man value 25 0 °C R 4, 39 float (4)
Temperature sensor NTC30k(154) Pt1000(148) R/W 4, 40 unsigned16 (2)
Temp. connection type 2 2 R 4, 41 unsigned8 (1)
Tertiary Value Parameters
Value S/cm R 4, 47 DS-33 (5)
Status 4, 47
Compensation Parameters
Reference temperature 25 0~100, 32~212 °C R/W 4, 48 float (4)
Compensation method NaCl(1) NaCl(1), TC(2), matrix(3) R/W 4, 49 unsigned8 (1)
Temperature coefficient 2.1 0~3.5 R/W 4, 45 float (4)
Matrix selection H
2
SO
4
0.5-5.0%, 0-100ºC(1), 2.5-25%,
0-100ºC(2) HCl 0-5%, 0-60ºC(3), 1-20%,
0-60ºC(4) HNO3 0.5-5.0%, 0-80ºC(5),
2.5-25%, 0-80ºC(6) NaOH 0.5-5.0%,
0-100ºC(7), 0.5-15%, 0-100ºC(8)
user defined(9) R/W 4, 50 unsigned8 (1)
Tertiary comp. method NaCl(1) NaCl(1), TC(2), matrix(3) R/W 4, 51 unsigned8 (1)
Tertiary temp. coefficient 2.1 0~3.5 R/W 4, 52 float (4)
Concentration Parameters
Concentration value 0 %/°C R 4, 46 DS-33 (5)
Concentration status 4, 46
Concentration Measuremen t Disabled(1) Enabled(2) % 4, 120 unsigned 8 (1)
