Instruction Manual

4-12 Profibus
IM 12A00A01-61E
4-4-3-2. Function Block Parameters SC202
Parameter Default Alternatives Unit R/W Slot, Index Data Type
(byte,bit) (bytes)
Primary Value Parameters
Primary value Type Conductivity(113) conductivity(113), resistivity(116) R 4, 27 unsigned16 (2)
Measured Value S/cm 4, 28
Status 4, 28
Conductivity sensor type 2 electrode(146) contact 2-electrode(146),
contact 4-electrode(163) R/W 4, 42 unsigned16 (2)
Secondary Value Parameters
Value -20~250, 0~500 °C R 4, 36 DS-33 (5)
Status 4, 36
Secondary value unit °C(1001) °C(1001), °F(1002) R/W 4, 37 unsigned16 (2)
Sensor temp comp Automatic(3) auto(3) R 4, 38 unsigned8 (1)
Sensor temp man value 25 0 °C R 4, 39 float (4)
Temperature sensor Pt1000(148) Pt1000(148), Pt100(128), Ni100(149),
8k55(151), Pb36/JIS6k(152) R/W 4, 40 unsigned16 (2)
Temp. connection type 2 2 R 4, 41 unsigned8 (1)
Tertiary Value Parameters
Value S/cm R 4, 47 DS-33 (5)
Status 4, 47
Compensation Parameters
Reference temperature 25 0~100, 32~212 °C R/W 4, 48 float (4)
Compensation method NaCl(1) NaCl(1), TC(2), matrix(3) R/W 4, 49 unsigned8 (1)
Temperature coefficient 2.1 0~3.5 %/°C R/W 4, 45 float (4)
Matrix selection HCl cation(1), Ammonia pure water(2),
Morpholine pure water(3), HCl 0-5%(4),
Natrium hydroxide 0-5%, user defined(9) R/W 4, 50 unsigned8 (1)
Tertiary comp. method NaCl(1) NaCl(1), TC(2), matrix(3) R/W 4, 51 unsigned8 (1)
Tertiary temp. coefficient 2.1 0~3.5 R/W 4, 52 float (4)
Concentration Parameters
Concentration value 0 R 4, 46 DS-33 (5)
Concentration status 4, 46
Concentration Measurement Disabled(1) Enabled(2) 4, 120 unsigned8(1)
Concentration 0% 0 0~100 % R/W 4, 121 float (4)
Concentration 100% 100 0~100 % R/W 4, 122 float (4)
Concentration Table 0% 0 0~1.999, 0~999MΩ•cm S/cm R/W 4, 123 float (4)
Concentration Table 5% 0.00005 S/cm R/W 4, 124 float (4)
Concentration Table 10% 0.0001 S/cm R/W 4, 125 float (4)
Concentration Table 15% 0.00015 S/cm R/W 4, 126 float (4)
Concentration Table 20% 0.0002 S/cm R/W 4, 127 float (4)
Concentration Table 25% 0.00025 S/cm R/W 4, 128 float (4)
Concentration Table 30% 0.0003 S/cm R/W 4, 129 float (4)
Concentration Table 35% 0.00035 0~1.999, 0~999MΩ•cm S/cm R/W 4, 130 float (4)
Concentration Table 40% 0.0004 S/cm R/W 4, 131 float (4)
Concentration Table 45% 0.00045 S/cm R/W 4, 132 float (4)
Concentration Table 50% 0.0005 S/cm R/W 4, 133 float (4)
Concentration Table 55% 0.00055 S/cm R/W 4, 134 float (4)
Concentration Table 60% 0.0006 S/cm R/W 4, 135 float (4)
Concentration Table 65% 0.00065 S/cm R/W 4, 136 float (4)
Concentration Table 70% 0.0007 0~1.999, 0~999MΩ•cm S/cm R/W 4, 137 float (4)
Concentration Table 75% 0.00075 S/cm R/W 4, 138 float (4)
Concentration Table 80% 0.0008 S/cm R/W 4, 139 float (4)
Concentration Table 85% 0.00085 S/cm R/W 4, 140 float (4)
Concentration Table 90% 0.0009 S/cm R/W 4, 141 float (4)
Concentration Table 95% 0.00095 S/cm R/W 4, 142 float (4)
Concentration Table 100% 0.001 S/cm R/W 4, 143 float (4)
