Profibus 4-11
IM 12A00A01-61E
4-4-3-1. Transducer block parameters PH202 (continued)
Parameter Default Alternatives Unit R/W Slot, Index Data Type
(byte,bit) (bytes)
Buffer1 at 20°C 4.00 R/W 4, 110 float (4)
Buffer1 at 25°C 4.01 R/W 4, 111 float (4)
Buffer1 at 30°C 4.02 R/W 4, 112 float (4)
Buffer1 at 35°C 4.02 R/W 4, 113 float (4)
Buffer1 at 40°C 4.04 R/W 4, 114 float (4)
Buffer1 at 45°C 4.05 R/W 4, 115 float (4)
Buffer1 at 50°C 4.06 R/W 4, 116 float (4)
Buffer1 at 55°C 4.08 R/W 4, 117 float (4)
Buffer1 at 60°C 4.09 R/W 4, 118 float (4)
Buffer1 at 65°C 4.11 R/W 4, 119 float (4)
Buffer1 at 70°C 4.13 R/W 4, 120 float (4)
Buffer1 at 75°C 4.15 R/W 4, 121 float (4)
Buffer1 at 80°C 4.16 R/W 4, 122 float (4)
Buffer Solution 2
Buffer2 ID 7.00 R/W 4, 123 unsigned8 (1)
Buffer2 at 0°C 6.98 R/W 4, 124 float (4)
Buffer2 at 5°C 6.95 R/W 4, 125 float (4)
Buffer2 at 10°C 6.92 R/W 4, 126 float (4)
Buffer2 at 15°C 6.90 R/W 4, 127 float (4)
Buffer2 at 20°C 6.88 R/W 4, 128 float (4)
Buffer2 at 25°C 6.87 R/W 4, 129 float (4)
Buffer2 at 30°C 6.85 R/W 4, 130 float (4)
Buffer2 at 35°C 6.84 R/W 4, 131 float (4)
Buffer2 at 40°C 6.84 R/W 4, 132 float (4)
Buffer2 at 45°C 6.83 R/W 4, 133 float (4)
Buffer2 at 50°C 6.83 R/W 4, 134 float (4)
Buffer2 at 55°C 6.83 R/W 4, 135 float (4)
Buffer2 at 60°C 6.84 R/W 4, 136 float (4)
Buffer2 at 65°C 6.84 R/W 4, 137 float (4)
Buffer2 at 70°C 6.85 R/W 4, 138 float (4)
Buffer2 at 75°C 6.85 R/W 4, 139 float (4)
Buffer2 at 80°C 6.86 R/W 4, 140 float (4)
Buffer Solution 3
Buffer3 ID 9 R/W 4, 141 unsigned8 (1)
Buffer3 at 0°C 9.46 R/W 4, 142 float (4)
Buffer3 at 5°C 9.40 R/W 4, 143 float (4)
Buffer3 at 10°C 9.33 R/W 4, 144 float (4)
Buffer3 at 15°C 9.28 R/W 4, 145 float (4)
Buffer3 at 20°C 9.23 R/W 4, 146 float (4)
Buffer3 at 25°C 9.18 R/W 4, 147 float (4)
Buffer3 at 30°C 9.14 R/W 4, 148 float (4)
Buffer3 at 35°C 9.10 R/W 4, 149 float (4)
Buffer3 at 40°C 9.07 R/W 4, 150 float (4)
Buffer3 at 40°C 9.04 R/W 4, 151 float (4)
Buffer3 at 50°C 9.01 R/W 4, 152 float (4)
Buffer3 at 55°C 8.99 R/W 4, 153 float (4)
Buffer3 at 60°C 8.96 R/W 4, 154 float (4)
Buffer3 at 65°C 8.94 R/W 4, 155 float (4)
Buffer3 at 70°C 8.92 R/W 4, 156 float (4)
Buffer3 at 75°C 8.90 R/W 4, 157 float (4)
Buffer3 at 80°C 8.89 R/W 4, 158 float (4)
