Foundation Fieldbus 3-47
error description resource block transducer block transducer block transducer block transducer block transducer block transducer block AI1 (channel = 1) AI2 (channel = 2) AI3 (channel = 3)
BLOCK_ERR DEV_ALARM BLOCK_ERR XD_ERROR PV.status SV.status TV.status OUT.status OUT.status OUT.status
primary value 0x80000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS BAD, SENS_FAIL
exceeds limits _ERR _FAIL
tertiary value 0x40000000 INPUT_FAILURE MECHANICAL_FAILURE
BAD, SENS_FAIL
BAD, SENS_FAIL
exceeds limits _ERR
temperature 0x20000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL BAD, SENS_FAIL
sensor open _ERR _FAIL _FAIL
temperature 0x10000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL BAD, SENS_FAIL
sensor shorted _ERR _FAIL _FAIL
glass impedance 0x08000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL
exceeds high limit _ERR _FAIL
glass impedance 0x04000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL
exceeds low limit _ERR _FAIL
reference impedance 0x02000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL
exceeds high limit _ERR _FAIL
reference impedance 0x01000000 INPUT_FAILURE MECHANICAL_FAILURE BAD, SENS
BAD, SENS_FAIL
BAD, SENS_FAIL BAD, SENS_FAIL
exceeds low limit _ERR _FAIL
calibration timer expired
0x00800000 NEEDS_MAINT_ BAD, NON BAD, NON BAD, NON_SPECIFIC BAD, NON_SPECIFIC
NOW_ERR _SPECIFIC _SPECIFIC
not used 0x00400000
not used 0x00200000
not used 0x00100000
not used 0x00080000
not used 0x00040000
mismatch between FF 0x00020000 NEEDS_MAINT_ ELECTRONICS_FAILURE BAD, DEV BAD, DEV BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL
interface and EXA NOW_ERR _FAIL _FAIL
parameter
EXA eeprom failure 0x00010000 NEEDS_MAINT_
DATA_INTEGRITY_ERROR
BAD, DEV BAD, DEV BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL
NOW_ERR _FAIL _FAIL
FF interface eeprom LOST_STATIC_ERR, 0x00008000 NEEDS_MAINT_
DATA_INTEGRITY_ERROR
BAD, DEV BAD, DEV BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL
failure LOST_NV_ERR NOW_ERR _FAIL _FAIL
Hart communication 0x00004000 NEEDS_MAINT_ ELECTRONICS_FAILURE BAD, DEV BAD, DEV BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL
failure NOW_ERR _FAIL _FAIL
EXA checksum error 0x00002000 ELECTRONICS_FAILURE BAD, DEV BAD, DEV BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL BAD, DEV_FAIL
FF interface checksum 0x00001000 _FAIL _FAIL
error
resource block out of OUT_OF_SERVICE_ERR 0x00000800 BAD, NON BAD, NON BAD, NON BAD, NON_SPECIFIC BAD, NON_SPECIFIC BAD, NON_SPECIFIC
service _SPECIFIC _SPECIFIC _SPECIFIC
transducer block out of 0x00000400 OUT_OF_ BAD, OUT BAD, OUT BAD, OUT_OF BAD, NON_SPECIFIC BAD, NON_SPECIFIC BAD, NON_SPECIFIC
service SERVICE_ERR _OF_SERVICE _OF_SERVICE _SERVICE
AI1 out of service 0x00000200
BAD, OUT_OF_SERVICE
AI1 in manual mode 0x00000100
AI1 in simulation mode SIMULATE_ACTIVE_ERR 0x00000080
AI1 not scheduled 0x00000040
AI2 out of service 0x00000020
BAD, OUT_OF_SERVICE
AI2 in manual mode 0x00000010
AI2 in simulation mode SIMULATE_ACTIVE_ERR 0x00000008
AI3 out of service 0x00000004
BAD, OUT_OF_SERVICE
AI3 in manual mode 0x00000002
AI3 in simulation mode SIMULATE_ACTIVE_ERR 0x00000001
