Instruction Manual

IM 12A00A01-61E
Foundation Fieldbus 3-39
3-39
Index Parameter name Factory Valid Description
Default Range
2035 COMP_METHOD NaCl NaCl, TC, matrix Method of process temperature compensation for the primary value
2036 COMP_MATRIX_SEL H
2
SO
4
H
2
SO
4
, 0 -100ºC, 0 - 5%, When matrix compensation is required one can
H
2
SO
4
, 0 -100ºC, 2.5 - 25% , make a selection out of 8 predefined matrices and
HCl, 0 - 60ºC, 0.5 - 5%, one user definable matrix
HNO
3
, 0 - 80ºC, 0.5 - 5%
HNO
3
, 0 -80ºC, 2.5 - 25%
NaOH, 0 -100ºC, 0.5 - 5%
NaOH, 0 -100ºC, 0.5 - 15%
User programmable matrix
2037 TERTIARY_COMP_METHOD NaCl NaCl, TC, matrix Method of process temperature compensation
for the second conductivity value
2038 TERT_TEMPERATURE 2.1 0 ~ 3.5 %/ºC Process temperature compensation factor for the
_COEFF second conductivity value
2039 ALARM_SUM -
2040 DEV_ALARM - Device Alarm is used to give the status of the analyser.
See separate table for error messages
2041 LOGBOOK1_RESET Idle Idle, Reset Reset the pointer to the first (oldest) event in logbook 1
2042 LOGBOOK1_EVENT - Event whereto the pointer is referenced. When parameter
is read, the pointer is increased by one.
2043 LOGBOOK2_RESET Idle Idle, Reset Reset the pointer to the first (oldest) event in logbook 2
2044 LOGBOOK2_EVENT - Event whereto the pointer is referenced. When parameter
is read, the pointer is increased by one
2045 LOGBOOK_CONFIG - Per event one can decide whether it should be logged and
in which logbook (1 or 2) it should be logged
2046 TEST_1 -
.... - 2047 to 2057 are, like 2046 and 2058, service parameters
2058 TEST_13 -
2059 CALIB_SENSOR_CONST 1.88 0.2~19.99 cm
-1
The calibrated cell constant [1/cm].
2060 MATRIX_TEMP_RANGE -20~140ºC, 0~280ºF The temperature values of the user defined matrix.
2061 SOLUTION_1 0~1.999 S/cm The conductivity values of solution 1.
2062 SOLUTION_2 0~1.999 S/cm The conductivity values of solution 2.
2063 SOLUTION_3 0~1.999 S/cm The conductivity values of solution 3.
2064 SOLUTION_4 0~1.999 S/cm The conductivity values of solution 4.
2065 SOLUTION_5 0~1.999 S/cm The conductivity values of solution 5.
2066 CONCENTRATION_ disabled 0=Not initialized, 1=disabled, Enabling/Disabling of concentration measurement.
MEASUREMENT 2=enabled
2067 CONCENTRATION_0 0 0~100 The concentration [%] corresponding to the 0 percent table value
2068 CONCENTRATION_100 100 0~100 The concentration [%] corresponding to the 100 percent table value
2069 CONC._TABLE_LOW 0~1.999 S/cm The first part of the concentration table (0 till 30 percent).
2070 CONC._TABLE_MID 0~1.999 S/cm The second part of the concentration table (35 till 65 percent).
2071 CONC._TABLE_HIGH 0~1.999 S/cm The third part of the concentration table (70 till 100 percent).
2072 E5_LIMIT 3 (3 S) 0~5 S The upper range accuracy limit of the analyzer [Siemens].
2073 E6_LIMIT 5e-6 (5 μS) 0~5 S The lower range accuracy limit of the analyzer [Siemens].
2074 DISPLAY_RESOLUTION 1 0 to 8 Display resolution, 0, Not initialized (can not change)
1, Auto Ranging, 2, x.xxx μS/cm, 3, xx.xx μS/cm,
4, xxx.x μS/cm, 5, x.xxx mS/cm, 6, xx.xx mS/cm,
7, xxx.x mS/cm, 8, xxxx mS/cm
2075 PASSCODE_MAINT 0 0, 111, 333, 777, Passcode used to protect the maintenance menu
888, 123, 957, 331, 546, 847
2076 PASSCODE_COMM 0 0, 111, 333, 777, Passcode used to protect the commissioning menu.
888, 123, 957, 331, 546, 847
2077 PASSCODE_SERVICE 0 0, 111, 333, 777, Passcode used to protect the service menu.
888, 123, 957, 331, 546, 847
2078 ERROR_CONFIG* 0=soft, 1=hard Soft/Hard fail configuration (checked = hard unchecked = soft).
2079 CONFIGURATION* autoreturn on Instrument specific configuration. See below for correct
bitnr. setting
2080 TRANSMITTER_TIME Transmitter time.”
2081 TEST_14 Service parameter.
