IM 12A00A01-61E
3-34 Foundation Fieldbus
Index Parameter name Factory Valid Description
Default Range
2075 PASSCODE_MAINTENANCE 0 0, 111, 333, 777, Passcode used to protect the maintenance menu.
888, 123, 957,
331, 546, 847
2076 PASSCODE_COMMISSIONING 0 0, 111, 333, 777, Passcode used to protect the commissioning menu.
888, 123, 957,
331, 546, 847
2077 PASSCODE_SERVICE 0 0, 111, 333, 777, Passcode used to protect the service menu.
888, 123, 957,
331, 546, 847
2078 SAMPLE_PV Process value of the sample taken.
2079 SAMPLE_PV2 Second process value of the sample taken.
2080 SAMPLE_TEMP Temperature of the sample taken.
2081 ERROR_CONFIG* Soft/Hard fail configuration
(checked = hard; unchecked = soft)
2082 CONFIGURATION* Instrument specific configuration
2083 TRANSMITTER_TIME Transmitter time.
2084 TEST
_
14 Service parameter.
* Enumerated parameters (4 bytes, 32 bits) where each bit can be set individually.
Error_config
0x00002000 (bit 14), “input 1 impedance exceeds low limit (E4.1)” ,
0x00001000 (bit 13), “input 1 impedance exceeds high limit (E5.1)” ,
0x00000800 (bit 12), “input 2 impedance exceeds low limit (E4.2)” ,
0x00000400 (bit 11) “input 2 impedance exceeds high limit (E5.2)” ,
0x00000200 (bit 10), “temperature sensor open (E7)” ,
0x00000100 (bit 9), “temperature sensor shorted (E8)” ,
0x00800000 (bit 24), “primary value exceeds limits (E9)” ,
0x00010000 (bit 17), “calibration timer expired (E16)”
Configuration
0x08000000 (bit 28), “Process compensation enabled” ,
0x00800000 (bit 24), “Aspot check enabled” ,
0x00400000 (bit 23), “Slope check enabled” ,
0x00200000 (bit 22), “Display resolution 0.01 pH” ,
0x00100000 (bit 21), “Auto return enabled” ,
0x00080000 (bit 20), “Maintenance timer enabled” ,
0x00002000 (bit 14), “Input 1 impedance measurement enabled” ,
0x00008000 (bit 16), “Input 1 impedance high” ,
0x00004000 (bit 15), “Input 1 impedance compensation enabled” ,
0x00000400 (bit 11), “Input 2 impedance measurement enabled” ,
0x00001000 (bit 13), “Input 2 impedance high” ,
0x00000800 (bit 12), “Input 2 impedance compensation enabled” ,
0x00000010 (bit 5), “Take sample”
