User guide

4-26
M-4662
TL Starts,stops,resets
computation(MATH)orclears
thecomputationdropoutstatus
display
Syntax
TL p1<terminator>
p1
Operation type
0
Computation start
1
Computation stop
2
Computation reset
3
Clear the computation dropout
status display
Example Start computation.
TL0
Description • You cannot execute this command while setup
data is being saved or loaded.
• You can execute this command on models
with the /M1 math option.
DS Switchestheexecutionmode
betweenoperationandbasic
setting
Syntax
DS p1<terminator>
p1
Event type
0
Operation Mode
1
Basic Setting Mode
Example Set the mode to Basic Setting Mode.
DS1
Description • You cannot set p1 to 1 while the MV is
measuring or computing, while the MV is
formatting an external storage medium, or
while the MV is saving data to an external
storage medium.
• You cannot set p1 to 0 while the MV is
formatting an external storage medium or
while the MV is saving data to an external
storage medium.
• To activate the settings that are changed with
the basic setting commands, you must save
the settings with the XE command. Make sure
to save the settings with the XE command
before changing from Basic Setting Mode to
Operation Mode. Otherwise, new settings will
not take effect.
• If you execute the DS command while the
screen display is stopped, the monitor will
resume.
LO Loadssetupdata
Syntax
LO p1,p2<terminator>
p1
File name (up to 32 characters)
p2
Media designation
0
CF slot
1
USB
Example Load setup data from the setup file SETFILE1
(.pdl extension).
LOSETFILE1
Description • Do not specify the file name extension.
• If you omit p2, the media designation is set to
the CF slot.
• This command loads the setup data of both
Setting Mode and Basic Setting Mode.
• This command loads the setup data in the root
directory of the specified storage medium.
• You cannot execute this command only if an
external storage medium is inserted in the
drive.
• You cannot execute this command while the
MV is memory sampling.
• Because the MV restarts after executing this
command, communications will be dropped.
LI Savessetupdata
Syntax
LI p1<terminator>
p1
File name (up to 32 characters)
p2
Media designation
0
CF slot
1
USB
Example Save the setup data of both the setting and basic
setting commands to the file SETFILE2 on a CF
card.
LISETFILE2
Description • Do not specify the file name extension.
• If you omit p2, the media designation is set to
the CF slot.
• The .pdl extension is added to the saved file.
• You cannot execute this command only if an
external storage medium is inserted in the
drive.
CM Setscommunicationinputdata
Syntax
CM p1,p2<terminator>
p1
Communication input channel number
p2
Communication input data
The selectable range is –9.9999E+29
to –1.0000E–30, 0, and 1.0000E–30 to
9.9999E+29.
Five significant digits.
Query
CM?
Example Set communication input channel C01 to
communication input data 1.0000E–10.
CMC01,1.0000E-10
Description You can execute this command on models with
the /M1 math option.
CE Entersdatainanexternalinput
channel
Syntax
CE p1,p2<terminator>
p1
External input channel number
p2
Data value (–30000 to 30000)
Query
CE[ p1]?
Example Set external input channel number 440 to 12345.
CE440,12345
Description You can execute this command on models with
the /MC1 external input channel option.
4.5SettingCommands(Control)
