Description • Parameter p2 is valid for the trend, digital, or
bar graph displays. Use the TP command to
set the scroll interval.
• Parameters p3 to p7 are valid for the trend
display.
PS Starts/stopsmeasurements
Syntax
PS p1<terminator>
p1
Measurement start/stop
0
Start
1
Stop
Example Start measurement.
PS0
Description When the MV starts measuring, it records the
display, event, and report data to the internal
memory.
AK Releasesthealarmoutput(alarm
acknowledge)
Syntax
AK p1<terminator>
p1
Alarm acknowledge execution (0)
Example Release the alarm output (execute alarm
acknowledge).
AK0
EV Executesmanualsample,
manualtrigger,snapshot,or
forced timeout
Syntax
EV p1<terminator>
p1
Operation type
0
Execute manual sampling.
1
Activate a manual trigger.
2
Take a snapshot.
3
Expire the display data timer.
4
Expire the even data timer.
Example Execute manual sampling.
EV1
Description EV1 is valid only when the key trigger is set
to ON with the TE command (sets sampling
conditions of the event data). It functions the
same as the key trigger.
CL ExecutesmanualSNTP
Syntax
CL p1<terminator>
p1
Manual SNTP execution (0)
Example Synchronize the clock manually.
CL0
CV Switchesthetrendupdaterate
Syntax
CV p1<terminator>
p1
Display rate (0, 1)
0
Switch to the primary trend update
rate (standard rate)
1
Switch to the secondary trend
update rate
Example Change the trend update rate to the secondary
trend update rate.
CV1
MS Writesamessage(displaysand
writes)
Syntax
MS p1,p2,p3<terminator>
p1
Message number (1 to 100)
p2
Destination where messages will be written
GROUP
Specify a single group
ALL
All groups
p3
Group number
Example Write the message number 8 message to group
1.
MS8,GROUP,1
Description • This command displays the message to the
screen and writes the message in the display
data and event data.
• If you omit p2, the message is written to all
groups.
BJ Writesafreemessage
Syntax
BJ p1,p2,p3,p4<terminator>
p1
Message number (1 to 10)
p2
Message (up to 32 characters)
p3
Destination type where messages will be
written
GROUP
Specify a single group
ALL
All groups
p4
Destination where messages will be written
If p3 is set to
GROUP
Group number
Example Use message number 3 and write the word
“ALARM” to all groups.BJ3,ALARM,ALL
Description If you omit p3, the message is written to all
groups.
EJ Changestheloginpassword
Syntax
EJ p1,p2,p3<terminator>
p1
Old password (up to eight alphanumeric
characters)
p2
New password (up to eight alphanumeric
characters)
p3
New password (up to eight alphanumeric
characters)
Example Change the old password “PASS001” to the new
password “WORD005.”
EJPASS001,WORD005,WORD005
4.5SettingCommands(Control)
