4.4SettingCommands(Setting)
M-4662
Ifp2issettoMONTH(day/timedesignation)
Syntax
TK p1,p2,p3,p4,p5<terminator>
p1
Timer number (1 to 4)
p2
Timer designation (MONTH)
p3
Day (1 to 28)
p4
Time (hh:mm) (00:00 to 23:59)
p5
Timer operation (SINGLE, REPEAT)
Ifp2issettoYEAR(month/day/timedesignation)
Syntax
TK p1,p2,p3,p4,p5,p6<terminator>
p1
Timer number (1 to 4)
p2
Timer designation (YEAR)
p3
Month designation (JAN, FEB, MAR, APR,
MAY, JUN, JUL, AUG, SEP, OCT, NOV,
DEC)
p4
Day designation (1 to 31) The selectable
range varies on the specified month.
P5
Time (hh:mm) (00:00 to 23:59)
p6
Timer operation (SINGLE, REPEAT)
Example Specify 8:30 on April 28 every year for timer
number 3.
TK3,APR,28,08:30,REPEAT
Query
TK[ p1]?
Example Specify hour 21 every Thursday for timer number
2.
TK2,WEEK,THU,21:00,REPEAT
TU Setsaneventaction
Syntax
TU p1,p2,p3,p4,p5,p6,p7<terminator>
p1
Logic number (1 to 40)
p2
Event type
NONE
REMOTE
RELAY
Alarm output relay
SWITCH
Internal switch
ALARM
Alarm occurrence
TIMER
Timer expiry
MATCHTIMETIMER
Match time expiry
USERKEY
USER key
p3
Event detail
p2
=REMOTE
Remote number (1 to
8)
p2
=RELAY
Relay number
p2
=SWITCH
Internal switch
number
p2
=TIMER
Timer number (1 to 4)
p2
=MATCHTIMETIMER
Match timer number
(1 to 4)
p2
=
Other Space
p4
Action type
MEMORYSTART/STOP
MEMORYSTART
MEMORYSTOP
TRIGGER
Event trigger
ALARMACK
Alarm acknowledge
MATHSTART/STOP
MATHSTART
MATHSTOP
MATHRESET
SAVEDISPLAY
Save display data to
an external storage
medium
SAVEEVENT
Save event data to an
external storage medium
MESSAGE
Write a message
SNAPSHOT
MANUALSAMPLE
TIMERRESET
Reset the relative timer
DISPLAYRATE1/2
Switch the trend update
rate
DISPLAYGROUPCHANGE
Switch the display group
FLAG
Raise a flag
TIMEADJUST
Synchronize the clock
PANELLOAD
Load settings
p5
Event detail 2
p4
=TIMERRESET
Timer number (1 to 4)
p4
=DISPLAYGROUPCHANGE
Group number
p4
=FLAG
Flag number (1 to 8)
p4
=MESSAGE
Message number (1 to
100)
p4
=PANELLOAD
Setup file number (1 to
3)
p6
Event detail 3
p4
=MESSAGE
Method of specifying
the destination where
messages are written
ALL
All display groups
SELECT
A specified display
group
p7
Event detail 4
If p6 is set to
SELECT
Group number
Some p4 parameters (action type) are not
selectable depending on p2 (event type).
Some p4 parameters (action type) are not
selectable depending on the settings or on the
installation of options.
Query
TU[ p1]?
Example
Execute memory start with the remote control input
(terminal 1).
TUREMOTE,1,MEMORYSTART
Description Set parameter p3 (relay number, internal switch)
according to the table in section 4.3.
SK Setsacomputationconstant
Syntax
SK p1,p2<terminator>
p1
Constants number
p2
Constant (–9.9999E+29 to –1.0000E–30,
0, 1.0000E–30 to 9.9999E+29, 5 significant
digits)
Query
SK[ p1]?
Example Set constants number K01 to 1.0000E–10.
SKK01,1.0000E-10
Description • You can execute this command on models
with the /M1 math option.
• You cannot execute this command while the
MV is measuring or computing.
• Set parameter p1 according to the table in
section 4.3.
