BasicSettings
Specify the SMTP server and POP before SMTP.
• SMTPservername
Enter the host name or IP address of the SMTP server.
• Portnumber
Unless specified otherwise, set the number to the default value. The default value is
25.
• Security
If you need to use POP before SMTP, set Security to PbS.
Recipients
Set the recipient e-mail addresses.
• Recipient1andRecipient2
Enter e-mail addresses. You can enter multiple addresses in each recipient box.
Separate each address with a space. You can enter up to 150 characters.
• Sender
Enter the sender e-mail address. You can enter up to 64 characters.
POP3Settings
If you need to use POP before SMTP, specify the POP3 server.
For the POP3 login procedure, see “Setting the POP3 Server Connection” in this section.
• POP3Servername
Enter the host name or IP address of the POP3 server.
• Portnumber
Unless specified otherwise, set the number to the default value. The default value is
110.
• Loginname
Enter the POP3 server login name.
• Password
Enter the POP3 server login password. You can enter up to 32 characters.
AlarmSettings
Specify the settings for sending e-mail when alarms occur or clear.
• Recipient1andRecipient2
Specify the recipients. For Recipient1 and Recipient2, select On to send e-mail or
Off to not send e-mail.
• ActiveAlarms
Sends an e-mail when an alarm occurs or clears. For alarms 1 to 4, select On to send
e-mail or Off to not send e-mail.
• IncludeINST
Select On to attach instantaneous value data that is acquired at the time of alarm
occurrence.
• Include source URL
Select On to attach the source URL. You can attach the URL when the Web server is
enabled.
• Subject
Enter the subject of the e-mail using up to 32 alphanumeric characters. The default
subject is Alarm_summary.
• Header 1 and Header 2
Enter Header 1 and Header 2 using up to 64 characters.
