StatusInformation4

Bit Name Description

0 A/D conversion complete Set to 1 when the A/D conversion of a measurement is

complete.

1 Medium access complete Set to 1 when the MV completes the saving of the display,

event, manual sampled, report, or screen image data file to

an external storage medium.

Set to 1 when the MV successfully completes the saving or

loading of setup data.

2 Report generation

complete

Set to 1 when the MV completes a report generation.

3 Timeout Set to 1 when the timer expires.

4 – –

5 – –

6 USER key detection Set to 1 when the USER key is pressed.

7 – –

StatusInformation5to8

All bits are zeroes.

6.2 Bit Structure of the Status Information
