ConguredAlarmInformationData
• The MV returns configured alarm information data in response to an FE6 command.
• The ID number of the output format is 26.
• The figure below indicates the format.
Number of blocks
Block size
Configured alarm information block 1
...
Configured alarm information block n
(Reserved) (Reserved)
2 bytes
1 byte
1 byte
1 byte1 byte
Version (Reserved)
2 bytes
Format Details
Item Description OutputValue
Version Format version 1
Number of blocks
*
Number of configured alarm information blocks Up to 348
Block size
*
Size of the of configured alarm information blocks 24
Block 1 to n Configured alarm information blocks Up to 8352 bytes
See Block Details.
* Returned in the byte order specified by the BO command.
Block Details
Item NumberofBytes Notes
Channel number
*
2 1 to 440
Decimal place 1 0 to 4
(Reserved) 1 0
Alarm type 4 The following settings are entered in order from
level 1 to 4.
0: Setting off, 1: H (high limit), 2: L (low limit),
3: h (difference high limit),4: l (difference low limit),
5: R (high limit on rate-of-change),
6: r (low limit on rate-of-change),
7: T (delay high limit), 8: t (delay low limit)
Alarm value
*
4×4 The alarm values are entered in order from level 1
to 4.
* Returned in the byte order specified by the BO command.
ManuallySampledData
• The MV returns the manually sampled data in response to the ME or MO command.
• The ID number of the output format is 17. See section 5.1 for details.
• For the data format, see the RD-MV1000/RD-MV2000 User’s Manual (IM RD-
MV1000-01E).
ReportData
• The MV returns the report data in response to the ME or MO command.
• The ID number of the output format is 18. See section 5.1 for details.
• For the data format, see the RD-MV1000/RD-MV2000 User’s Manual (IM RD-
MV1000-01E).
DisplayData(Text)
• The MV returns the display data in response to an ME command.
• The ID number of the output format is 29. See section 5.1 for details.
• For the data format, see the RD-MV1000/RD-MV2000 User’s Manual (IM RD-
MV1000-01E).
EventData(Text)
• The MV returns the display data in response to an ME command.
5.3 Binary Data Output Format
