EM Starts/stopsthee-mail
transmission function
Syntax
EM p1<terminator>
p1
Operation type
0
Start
1
Stop
Example Start the e-mail transmission function.
EM0
Description To use the e-mail transmission function,
you must set the Ethernet interface, e-mail
addresses, and contents to be transmitted.
CU ManuallyrecoversModbus
Syntax
CU p1<terminator>
p1
Communication type
0
Modbus client (Ethernet)
1
Modbus master (serial)
BV Enterscharacters
Syntax
BV p1,p2<terminator>
p1
0
p2
Character string (up to 100 characters)
Example Enter user123.
BV0,user123
KE Keyoperationcommand
Syntax
KE p1<terminator>
p1
Key type
F1
– F7
Soft keys 1 to 7
ESC
ESC key
MENU
MENU key
FUNC
FUNC key
START
START/STOP key
HISTORY
HISTORY key
USER
USER key
T/DIV
T/DIV key
0 – 9
Number 0 to 9 keys
MINUS
Number minus key
DOT
Number decimal key
DISP
DISP/ENTER key
UP
Up arrow key
DOWN
Down arrow key
RIGHT
Right arrow key
LEFT
Left arrow key
Example Press the DISP/ENTER key.
KEDISP
Description Operates in the same way as the keys on the
MV. For a key sequence, transmit the commands
in the same order that you would press the keys
on the MV.
YC Clearsmeasured/computeddata
andinitializessetupdata
Syntax
YC p1<terminator>
p1
Type of data to be cleared
0
Clear measured/computed data
and initialize setup data
2
Clear measured/computed data
IR Resetstherelativetimer
Syntax
IR p1<terminator>
p1
Timer number to be reset
0
All timers
1 – 4
Timer number 1 to 4
MA Resetsamatchtimer
Syntax
MA p1
P1
Match timer number to be reset (1 to 4)
Example Reset match timer number 3.
MA3
Description • An error will occur if the timer operation of the
match timer is set to repeat.
• Nothing will occur if the single match timer has
not expired.
NR Setsthetrendupdaterate
Syntax
NR p1,p2<terminator>
p1
1
p2
Trend update rate [/div] (15S, 30S, 1MIN,
2MIN, 5MIN, 10MIN, 15MIN, 20MIN, 30MIN,
1H, 2H, 4H, 10H)
Query
NR[ p1[,p2]]?
Example Set the trend update rate to 5 min/division.
NR1,5MIN
Description • You cannot set the trend update rate if the
memory data type is event + display.
• The logging number is fixed to 1.
• Set the data update rate and auto save rate
first with the SW command and then set the
trend update rate with the NR command.
4.5SettingCommands(Control)
