Instruction Manual

Communication (Ethernet) > Modbus client > Auto setting
Setting Selectable Range or Choices Default Value
Auto setting of MODBUS client will be
executed.
The following settings will be cleared.
OK?
Yes/No −
Communication (Serial) > Basic settings
Setting Selectable Range or Choices Default Value
Serial
Baud rate 1200/2400/4800/9600/19200/38400 9600
Data length 7/8 8
Parity Odd/Even/None Even
Handshaking Off:Off/XON:XON/XON:RS/CS:RS Off:Off
Address Numeric value (1 to 99) 1
Protocol Normal/Modbus/Modbus-M Normal
Communication (Serial) > Modbus master >Basic settings
Setting Selectable Range or Choices Default Value
Modbus master basic settings
Read cycle 125ms/250ms/500ms/1s/2s/5s/10s 1s
Timeout 125ms/250ms/500ms/1s/2s/5s/10s/1min 1s
Retrials Off/1/2/3/4/5/10/20 1
Inter-block delay Off/5ms/10ms/15ms/45ms/100ms Off
Auto recovery Off/1min/2min/5min/10min/20min/30min/1h 2min
Communication (Serial) > Modbus master > Command settings
Setting Selectable Range or Choices Default Value
Master command number 1-8/9-16 1-8
1 to 16 Off/R/R-M/W/W-M Off
Master > First Varies depending on the send command type −
Master > Last Varies depending on the send command type −
Slave > Address Numeric value (1 to 247) 1
Slave > Registers Numeric value (register number)
R, R-M:30001
W, W-M: 40001
Slave > Type INT16/UINT16/INT32_B/INT32_L/UINT32_B/
R, R-M, W: INT16
UINT32_L/FLOAT_B/FLOAT_L
W-M: INT32_B
Status relay
Setting Selectable Range or Choices Default Value
Status relay
Memory/Media status On/Off Off
Measurement error On/Off Off
Communication error On/Off Off
Memory stop On/Off Off
End
Setting Selectable Range or Choices Default Value
Do you want to store and make the new
settings take effect?
Yes/No/Cancel −
Default RD-MV2000 Settings
56
M-4663
