Instruction Manual

Menu Tab
Alarm
Setting Selectable Range or Choices Default Value
Basic setting
Reflash On/Off Off
Rate of change > Decrease 1 to 32 1
Rate of change > Increase 1 to 32 1
Indicator Hold/Nonhold Nonhold
Switch, Relay
Internal Switch > AND None/S01/S01-S02/…/S01-S29/S01-S30 None
Relay > AND None/I01/I01-I02/…/I01-I15/I01-I16 None
Relay > Action Energize/De_energize Energize
Relay > Hold Hold/Nonhold Nonhold
Relay > Relay Action on ACK Normal/Reset Normal
Hysteresis
Meas CH > High/Low Numeric value (0.0 to 5.0) 0.5
Meas CH > Delta High/Low Numeric value (0.0 to 5.0) 0.0
Math CH > High/Low Numeric value (0.0 to 5.0) 0.0
Ext. CH > High/Low Numeric value (0.0 to 5.0) 0.0
A/D,Memory
Setting Selectable Range or Choices Default Value
Scan interval > Scan mode Normal/Fast Normal
Normal > Scan interval 125ms/250ms (RD-MV2008) 125ms
1s/2s/5s (RD-MV2010, RD-MV2020, RD-MV2030, RD-
MV2040, RD-MV2048)
1s
Normal > A/D integrate Auto/50Hz/60Hz/100ms Auto
Fast > Scan interval 25ms (RD-MV2008) 25ms
125ms (RD-MV2010, RD-MV2020, RD-MV2030, RD-MV2040,
RD-MV2048)
125ms
Fast > A/D integrate 600Hz 600Hz
Memory
Data kind Display/E+D/Event Event
Burnout,RJC
Setting Selectable Range or Choices Default Value
First-CH, Last-CH Numeric value (channel number) 001 to 048 001
Burnout
Mode Off/Up/Down Off
RJC
Mode Internal/External Internal
Volt Numeric value (–20000 to 20000)µV 0
Default RD-MV2000 Settings
50
M-4663
