Instruction Manual

Setting Submenu Choices
INFORMATION ALARM SUMMARY Select/Hide
MESSAGE SUMMARY
MEMORY SUMMARY
MODBUS CLIENT
MODBUS MASTER
RELAY
REPORT DATA
COLUMN BAR
TO HISTORY
TO HISTORY(DISP)
TO HISTORY(EV)
TO OVERVIEW
CHANG SORT KEY
ASCENDING ORDER/DESCENDING ORDER
DATA SAVE MODE
SELECT SAVE
M.SAMPLE SAVE
REPORT SAVE
ALL SAVE
CHANGE DISP ITEM
CHANGE DATA KIND
FILENAME DISPLAY
CHANGE REPORT CH
DUAL GRAPH/SINGLE GRAPH
SELECT COLUMN
REPORT GROUP 1 to REPORT GROUP6
EXPAND
LOG LOGIN
ERROR
COMMUNICATION
FTP
MAIL
WEB
SNTP
DHCP
MODBUS
4 PANEL MIX
ALL TREND
ALL DIGITAL
ALL BAR
EXPAND —
Date/Time > Time settings
Setting Selectable Range or Choices Default Value
Time set — 08/01/01
Date/Time > Daylight Saving Time
Setting Selectable Range or Choices Default Value
DST > Use/Not Use/Not Use
Start time
Month 1/2/.../11/12 3
Day order 1st/2nd/3rd/4th/Last 2nd
Day of the week SUN/MON/TUE/WED/THU/FRI/SAT SUN
Hour of the day 0 to 23 2
End time
Month 1/2/.../11/12 11
Day order 1st/2nd/3rd/4th/Last 1st
Day of the week SUN/MON/TUE/WED/THU/FRI/SAT SUN
Hour of the day 0 to 23 1
Default RD-MV2000 Settings
47
M-4663
