Instruction Manual

Setting Selectable Range or Choices Default Value
Range > Alarm 1 to 4 On/Off Off
Type H/L/h/l/R/r/T/t H
Value Numeric value 0.00
Relay On/Off On/Off Off
No. I01 to I06/I11 to I16/S01 to S30 I01
Detect On/Off On
Measchannel>Tag,Memorysample,Alarmdelay
Setting Selectable Range or Choices Default Value
First-CH, Last-CH Numeric value (channel number) 1 to 48 001
Tag > Characters Character string (up to 16 characters) —
Memory sample > On/Off On/Off On
Alarm delay > Time Numeric value (1 to 3600) s 10
Meas channel > Moving average
Setting Selectable Range or Choices Default Value
First-CH, Last-CH Numeric value (channel number) 1 to 48 001
Moving average > On/Off On/Off Off
Count Numeric value (2 to 400) 2
Meas channel > Color
Setting Selectable Range or Choices Default Value
Group of channel 001–010/011–020/021–030/031–040/041–048 001-010
Color Red, Green Blue, B.violet, Brown, Orange, Y.green,
Lightblue, Violet, Gray, Lime, Cyan, Darkblue, Yellow,
Lightgray, Purple, Black, Pink, L.brown, L.green,
Darkgray, Olive, DarkCyan, S.green
Colors assigned in order to
groups
Red, Green Blue, B.violet, Brown,
Orange, Y.green, Lightblue,
Violet, Gray
Measchannel>Zone,Scale,Bargraph
Setting Selectable Range or Choices Default Value
First-CH, Last-CH Numeric value (channel number) 1 to 48 001
Zone Lower Numeric value (0 to 95) % 0
Upper Numeric value (5 to 100) % 100
Scale Position Off/1/2/3/4/5/6/7/8/9/10 1
Division 4/5/6/7/8/9/10/11/12/C10 10
Bar graph Base position Normal/Center/Lower/Upper Normal
Division 4/5/6/7/8/9/10/11/12 10
Meas channel > Partial
Setting Selectable Range or Choices Default Value
First-CH, Last-CH Numeric value (channel number) 1 to 48 001
Partial On/Off On/Off Off
Expand Numeric value (1 to 99)% 50
Boundary Numeric value (minimum span value + 1 digit to
maximum span value – 1 digit)
0.0000
Default RD-MV2000 Settings
