Instruction Manual

Removing the CF Card
1.
Press FUNC once.
2.
Press Media eject once.
CF card icon
3.
Press the CF soft key once. The message, “Media can be removed safely”
appears. The CF card icon is blue.
4.
Open the cover.
5.
Press the CF card eject button. When you eject the CF card, the CF card icon
disappears.
Push on the eject button until it clicks.
The eject button remains depressed.
Pinch the left and right sides of the CF card
and remove it.
Eject button
6.
Close the cover.
Operation complete.
Note
If you remove the CF card without carrying out the media eject procedure, the message “Media
was removed compulsorily” appears. Remove the CF card by carrying out the procedure above
to prevent damage to the stored data.
Viewing Data with DAQSTANDARD
You can use the DAQSTANDARD software that comes with the RD-MV2000 to view data
saved to a CF card. For more information, see the DAQSTANDARD User’s Manual (IM
04L41B01-01E).
