Foreword Thank you for purchasing the MV 2000 (hereafter referred to as the MV). This manual explains the minimum steps required to start measuring quickly. It also contains a list of default RD-MV2000 settings. Please keep it for reference. The following five manuals are provided as RD-MV2000 manuals. Paper Manual Manual Title RD-MV2000 First Step Guide Control of Pollution Caused by the Product Manual No. IM RD-MV200002E IM MV1000-91C Description This manual. It is also provided in the CD.
Safety Precautions • This instrument conforms to IEC safety class I (provided with terminal for protective grounding), Installation Category II, and EN61326-1 (EMC standard), Measurement Category II (CAT II)*. * Measurement category II (CAT II) applies to measuring circuits connected to low voltage installation, and electrical instruments supplied with power from fixed equipment such as electric switchboards.
WARNING • Use the Correct Power Supply Ensure that the source voltage matches the voltage of the power supply before turning the power ON. • Use the Correct Power Cord and Plug To prevent electric shock or fire, be sure to use the power cord supplied by Omega. The main power plug must be plugged into an outlet with a protective earth terminal. Do not disable this protection by using an extension cord without protective earth grounding.
• Handling Precautions of the Software • Omega makes no warranties regarding the software accompanying this product except those stated in the WARRANTY that is provided separately. • Use the software on a single PC. • You must purchase another copy of the software, if you are to use the software on another PC. • Copying the software for any purposes other than backup is strictly prohibited. • Please store the original media containing the software in a safe place.
Protection of Environment Control of Pollution Caused by the Product For details, see Control of Pollution Caused by the Product (IM MV1000-91C). Proper Disposal of This Product This is an explanation of how to dispose of this product based on Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC. This directive is only valid in the EU. • Marking This product complies with the WEEE Directive (2002/96/EC) marking requirement.
Memo M-4663 9
Checking the Contents of the Package Unpack the box and check the contents before operating the instrument. If some of the contents are not correct or missing or if there is physical damage, contact the dealer from which you purchased them. RD-MV2000 There is a name plate on the side panel of the MV. Check that the model name and suffix code given on the name plate match those on your order. Main name plate NO.
Checking the Contents of the Package Model code Options Suffix Code /A1 /A2 /A3 /A4 /C2 /C3 /F1 /M1 /N1 /N2 /N3 /R1 /TPS4 /PM1 /CC1 /MC1 1 Does not come with an AC adapter if the power cord suffix code is W. 2 Can be selected if the supply voltage suffix code is -2. 3 The /A1, /A2, /A3, and A4 options cannot be combined. 4 The /A4 and /F1 options cannot be combined. 5 The /C2 and /C3 options cannot be combined.
Checking the Contents of the Package No. Name AC adapter and power cord for AC adapter Part number/ Model B8805GV B9988YA B9988YB B9988YC A1069WD B9988YJ Qty. Notes 1 Only included if the supply voltage suffix code is -2 (except for power cord suffix W). When the supply voltage suffix code is -2, one of the following cables is included, depending on the power cable suffix code. Power cord suffix code D. Maximum rated voltage: 125 V Power cord suffix code F.
How to Use This Manual Conventions Used in This Manual • This user’s manual assumes that the display language is set to English (language suffix code -2). • For information on setting the display language, see section 9.4, “Changing the Display Language” in the MV1000/RD-MV2000 User’s Manual (IM MV1000-01E). Unit K stands for 1024. Example: 768 KB (file size) k stands for 1000.
Names of Parts Front View With the cover open Carrying handle LCD screen Trend display and all other operation and configuration screens are displayed here. Power switch Power indicator Glows red when the power is ON CF card access indicator USB 1.1 port CF card slot CF card eject button Cover Rear Panel Serial port (/C3 option) An RS-422/RS-485 port USB 1.
Basic Operation Panel Keys LCD screen Keys DISP/ENTER key Up arrow key Left arrow key Down arrow key START/STOP key Starts or stops memory sampling HISTORY key • When using the history function: Switches to the history screen • When using the favorite function: Switches between the operation screens that have been registered to it (max.
Basic Operation Entering Values and Characters The character/number input keys and DISP/ENTER key are used to set the date/time, set the display span of the input range, set tags, set message strings, enter passwords, etc. Character/Number input keys DISP/ENTER key and four arrow keys (up, down, left, and right) Entering Values When a window for entering a value appears, enter the value by performing the following key operation. • Left and right arrow keys: Selects the input position.
Memo M-4663 17
RD-MV2000 Workflow To set up the MV for quick use in the field, follow these steps: Install Connect Cables Turn ON Set Measurement Range Install the MV. Installation: Page 20 Connect input/output wires and the power cord to the rear panel terminals. Connecting Input Cables: Page 22, Connecting a Power Cable: Page 26 Turn the power ON. Connecting a Power Cable: page 29 Select the measurement range, and configure the data save options from the Quick settings menu.
Installation Location Install the MV indoors in an environment that meets the following conditions: • Temperature of 0 to 40°C Install the MV in a location where the temperature is 0 to 40°C, and the humidity is 20 to 80% RH (5 to 40°C). Only use the MV when there is no condensation on it. Note Condensation may form when moving the MV from a low temperature/humidity environment to a high temperature/humidity environment, or when there is a sudden change in temperature.
Installation Installation Procedure Install the MV on a flat surface. Note • • You cannot put the MV in a stack. You can put rubber feet on the bottom of the MV. Please use the ones that come with the MV. • Using the stand When using the stand, push it out until it locks into place. Push the stand back in when you store the MV.
Connecting Input Cables Wiring to the Signal Input Terminals WARNING • To prevent electric shock, make sure that the power source is turned OFF. CAUTION • Exposing the input and output signal cables connected to the MV to high tension may damage the cables and the MV terminals. Do not stretch the cables to their limit, and make sure that the terminals are not being pulled on. • To prevent fire, only use signal cables with a temperature rating of 70°C or above.
Connecting Input Cables Connecting the input wires in parallel with other devices can cause signal degradation, affecting all connected devices. If you have to make a parallel connection, then • Turn the burnout detection function OFF. • Ground the instruments to the same point. • Do not turn other instruments ON or OFF during operation. This can have adverse effects on the other instruments. • Do not connect RTDs in parallel.
Connecting Input Cables Screw Terminal Clamp Terminal CH4 CH2 CH3 CH1 MV2008 input terminal block CH3 CH1 /b +/A -/B /b +/A -/B CH10 CH8 CH6 CH4 CH2 CH9 CH7 CH5 CH3 CH1 Input terminal block 1 of the MV2010, MV2020, MV2030, and MV2040 MV2048 input terminal block 1 CH4 CH2 CH9 CH7 CH5 CH3 CH1 CH10 CH8 CH6 CH4 CH2 /b +/A -/B /b +/A -/B CH12 CH10 CH8 CH6 CH4 CH2 CH11 CH9 CH7 CH5 CH3 CH1 CH11 CH9 CH7 CH5 CH3 CH1 /b +/A -/B /b +/A -/B CH12 CH10 CH8 CH6 CH4 CH2 Wiring Screw Terminals TC input
Connecting Input Cables Wiring Clamped Terminals Connect the wires. Remove the terminal block. Recommended length of stripped wire: 7 mm Connect the terminal block. Flat-blade screwdriver Recommended wire size 0.08 to 1.5 mm2 (AWG28 to 16) Hold both ends of the terminal block and pull straight. Input signal wire First, loosen the screw at the front using a flat-blade screwdriver. Insert the input signal wire into the slit on the left side of the terminal block, and fasten the screw at the front.
Connecting a Power Cable Connecting the Power Cord (if the power supply voltage suffix code is -1) Precautions to Be Taken While Connecting the Power Supply Make sure to follow the warnings below when connecting the power supply. To prevent electric shock and damage to the MV, observe the following warnings.
Connecting a Power Cable Connecting the Power Cord (if the power supply voltage suffix code is -2) When Using an AC Adapter Precautions to Be Taken While Connecting the Power Supply Make sure to follow the warnings below when connecting the power supply. To prevent electric shock and damage to the MV, observe the following warnings. WARNING • To prevent electric shock, make sure that the power source is turned OFF. • Only use the power cord that Omega provides for use with the MV.
Connecting a Power Cable When Using a DC Power Supply Precautions to Be Taken While Connecting the Power Supply Make sure to follow the warnings below when connecting the power supply. To prevent electric shock and damage to the MV, observe the following warnings. WARNING • To prevent electric shock, make sure that the power source is turned OFF. • To prevent fire, use cables with a cross-sectional area of 0.5 mm2 (AWG20) or more.
Connecting a Power Cable Turning the Power ON/OFF Turning the Power ON CAUTION Before turning ON the power switch, check that • The power cord/wires are connected correctly to the MV. • The MV is connected to the correct power supply (see page 64). If the input wires are connected in parallel with other devices, do not turn the power switch of the MV or another device ON or OFF during operation. This can have adverse effects on the measured values. Turn ON the power switch.
Quick Settings Using the quick settings function, you can switch quickly to the measurement channel (measurement range and alarm) and data save configuration screens by pressing T/DIV. Procedure Operate the MV from the Quick settings screen according to the procedure described below.
Quick Settings Press T/DIV. Change the display-data save settings 1. Select the Trend/Storage interval. Press the 1min soft key. 2. Select the Save interval. Press the 1h soft key. Note This screen does not appear with the default settings. In A/D, Memory in Basic setting mode, set the data type to E+D Press T/DIV. Change the event data display settings. 1. Select the Sample rate. Press the 1s soft key. 2. Select the recording mode. Press the Free soft key. 3. Select the Data length.
Measurement Inserting the CF Card 1. Open the cover. CAUTION is h T e id s p u “This side up” facing up CF card 2. Insert the CF card into the slot. The CF card icon is displayed. If the MV does not recognize the CF card, try reinserting it. 3. Close the cover. Check that the CF card slot eject button is depressed before closing the cover. Operation complete.
Measurement Starting the Memory Sample 1. Press START/STOP once. Memory sampling starts, and the key blinks green. Recording data Memory sampling progress DISP: Display data EVENT: Event data START/STOP key Operation complete. Stopping the Memory Sample 1. Press the START/STOP key when it is blinking green. Display the confirmation window 2. Select Mem+Math or Memory using the left and right arrow keys. Memory: Stops memory sampling. Mem+Math: Stops memory sampling and computation (option).
Measurement Removing the CF Card 1. Press FUNC once. 2. Press Media eject once. CF card icon 3. Press the CF soft key once. The message, “Media can be removed safely” appears. The CF card icon is blue. 4. Open the cover. 5. Press the CF card eject button. When you eject the CF card, the CF card icon disappears. Push on the eject button until it clicks. The eject button remains depressed. Pinch the left and right sides of the CF card and remove it. Eject button 6. Close the cover.
Memo 34 M-4663
Default RD-MV2000 Settings The setting mode and basic setting mode settings and their default values are listed in this section.
Default RD-MV2000 Settings • Menu Page 51 Page 51 Page 51 Page 521 Pages 52 and 531 Page 532 Page 53 Pages 53 to 56 Page 572 Page 572 Page 57 1 The function will be displayed if you choose to use it in Environment.
Default RD-MV2000 Settings Setting Mode Settings and Default Values Menu Tab Meas channel > Range, Alarm Setting First-CH, Last-CH Range>Mode Mode=Volt Range Span Lower Span Upper Mode=TC Range Span Lower Span Upper Mode=RTD Range Span Lower Span Upper Mode=Scale Type Range Span Lower Span Upper Scale Lower Scale Upper Unit Mode=Delta Type Range Span Lower Span Upper Ref.
Default RD-MV2000 Settings Setting Range > Alarm 1 to 4 Type Value Relay On/Off No. Detect Selectable Range or Choices On/Off H/L/h/l/R/r/T/t Numeric value On/Off I01 to I06/I11 to I16/S01 to S30 On/Off Default Value Off H 0.
Default RD-MV2000 Settings Meas channel > Alarm mark, Color scale band Setting First-CH, Last-CH Alarm mark Mark kind Indicate on Scale Alarm mark color > Alarm 1 to 4 Selectable Range or Choices Numeric value (channel number) 1 to 48 Alarm/Fixed On/Off Default Value 001 Alarm Off Red, Green Blue, B.violet, Brown, Orange, Y.green, Lightblue, Violet, Gray, Lime, Cyan, Darkblue, Yellow, Lightgray, Purple, Black, Pink, L.brown, L.green, Darkgray, Olive, DarkCyan, S.
Default RD-MV2000 Settings Math channel > TLOG, Rolling average Setting First-CH, Last-CH TLOG Timer type Timer No.
Default RD-MV2000 Settings Math channel > Math start action Setting Math start action > Math start Selectable Range or Choices Off/Start/Rst+St Default Value Start Ext. channel > Range, Alarm Setting First-CH, Last-CH Ext. range Ext.
Default RD-MV2000 Settings Ext. channel > Alarm mark, Color scale band Setting First-CH, Last-CH Alarm mark Mark kind Indicate on Scale Selectable Range or Choices Numeric value (external input channel number) 201 to 440 Alarm/Fixed On/Off Alarm mark color > Alarm 1 to 4 Red, Green Blue, B.violet, Brown, Orange, Y.green, Lightblue, Violet, Gray, Lime, Cyan, Darkblue, Yellow, Lightgray, Purple, Black, Pink, L.brown, L.green, Darkgray, Olive, DarkCyan, S.
Default RD-MV2000 Settings Display > Trend, Bar graph, LCD, Monitor Setting Trend Bar graph LCD Monitor Direction Trend clear Message direction Scale > Digit Scale > Value indicator Trend line Grid Second interval Direction Brightness Backlight saver > Mode Backlight saver > Saver time Backlight saver >Restore Background > Display Background > Historical trend Scroll time Jump default display Selectable Range or Choices Horizon/Vertical/Wide/Split On/Off Horizon/Vertical Normal/Fine Mark/Bargraph 1/2/3
Default RD-MV2000 Settings Timer, Event action > Timer Setting Timer No. Timer Mode Mode = Relative Interval Reset at Math Start Mode = Absolute Interval Ref.
Default RD-MV2000 Settings Setting Action Event = Timer Timer No. Action Event = MatchTimeTimer Timer No. Action Event = Alarm Action Group No.
Default RD-MV2000 Settings Menu customize > Function menu Setting Pause Display Message Free message Media eject Snapshot Manual sample Alarm ACK LCD Saver Trigger Save display Save event Save stop Math start Math reset Math ACK Timer reset Match T Reset Keylock Logout Password change Second speed Batch Text field Favorite regist 4Panel Standard display System info Network info SNTP E-Mail start E-Mail test FTP test Choices Select/Hide/Transfer Menu customize > Display menu Setting ESC TREND TREND HISTO
Default RD-MV2000 Settings Setting INFORMATION LOG 4 PANEL EXPAND Submenu ALARM SUMMARY MESSAGE SUMMARY MEMORY SUMMARY MODBUS CLIENT MODBUS MASTER RELAY REPORT DATA COLUMN BAR TO HISTORY TO HISTORY(DISP) TO HISTORY(EV) TO OVERVIEW CHANG SORT KEY ASCENDING ORDER/DESCENDING ORDER DATA SAVE MODE SELECT SAVE M.
Default RD-MV2000 Settings Basic Setting Mode Settings and Default Values Environment Tab Operating environment Setting Operating environment Tag/Channel Language Temperature Decimal Point Type Selectable Range or Choices Default Value Tag/Channel English/Japanese/German/French/Chinese/Korean C/F Point/Comma Tag English C Point Environment > View, Message, Input, Alarm Setting View Trend type Partial Trend rate switching Message Write group Power-fail message Change message Input Value on over-range A
Default RD-MV2000 Settings Environment > Math, Report Setting Math Value on Error Value on Overflow > SUM, AVE Value on Overflow > MAX, MIN, P-P Report Report select > 1 Report select > 2 Report select > 3 Report select > 4 File type Selectable Range or Choices Default Value +Over/-Over Error/Skip/Limit Over/Skip +Over Skip Over Max/Min/Ave/Sum/Inst Off/Max/Min/Ave/Sum/Inst Off/Max/Min/Ave/Sum/Inst Off/Max/Min/Ave/Sum/Inst Separate/Combine Ave Max Min Sum Separate Selectable Range or Choices Yes/No/
Default RD-MV2000 Settings Menu Tab Alarm Setting Basic setting Reflash Rate of change > Decrease Rate of change > Increase Indicator Switch, Relay Internal Switch > AND Relay > AND Relay > Action Relay > Hold Relay > Relay Action on ACK Hysteresis Meas CH > High/Low Meas CH > Delta High/Low Math CH > High/Low Ext.
Default RD-MV2000 Settings Keylock Setting Keylock Password Key action > START/STOP Key action > HISTORY Key action > MENU Key action > USER Key action > DISP/ENTER Key action > T/DIV Media/USB > External media Media/USB > Load settings Action of Function > AlarmACK Action of Function >Message / Batch Action of Function >Math Action of Function >Data save Action of Function >E-mail / FTP Action of Function >Time set Action of Function >Display Function Selectable Range or Choices Default Value Character
Default RD-MV2000 Settings Authority of user Setting Authority of user Authority of user Key action > START/STOP Key action > HISTORY Key action > MENU Key action > USER Key action > DISP/ENTER Key action > T/DIV Media/USB > External media Media/USB > Load settings Action of Function > AlarmACK Action of Function >Message / Batch Action of Function >Math Action of Function >Data save Action of Function >E-mail / FTP Action of Function >Time set Action of Function >Display Function Selectable Range or Choi
Default RD-MV2000 Settings Communication (Ethernet) > DNS settings Setting Server search order Primary Secondary Domain suffix search order Primary Secondary Selectable Range or Choices Default Value Numeric value (0.0.0.0 to 255.255.255.255) Numeric value (0.0.0.0 to 255.255.255.255) 0.0.0.0 0.0.0.
Default RD-MV2000 Settings Communication (Ethernet) > E-mail > POP3 settings Setting POP3 Settings POP3 Server name Port number Login name Password Selectable Range or Choices Default Value Character string (up to 64 characters) Numeric value (0 to 65535) Character string (up to 32 characters) Character string (up to 32 characters) − 110 − ******...
Default RD-MV2000 Settings Communication (Ethernet) > FTP client Setting FTP transfer file Disp&Event data Report Snapshot FTP connection FTP server name Port number Login name Password Account PASV mode Initial path Selectable Range or Choices Default Value On/Off On/Off On/Off Primary/Secondary Character string (up to 64 characters) Numeric value (0 to 65535) Character string (up to 32 characters) Character string (up to 32 characters) Character string (up to 32 characters) On/Off Character string (up
Default RD-MV2000 Settings Communication (Ethernet) > Modbus client > Auto setting Setting Auto setting of MODBUS client will be executed. The following settings will be cleared.
Default RD-MV2000 Settings Initialize Tab Clear settings and data Setting Are you sure you want to initialize “Settings + Measure&Math data”? Selectable Range or Choices Yes/No Default Value − Selectable Range or Choices Yes/No Default Value − Clear data only Setting Are you sure you want to initialize “Measure&Math data”? M-4663 57
