IM 01E20C01-01E
6-7
6. PARAMETER DESCRIPTION
T0607-2.EPS
Item
Name
Display unit
(BRAIN)
Data range
Display unit
/BRAIN
Default value
(*): Indicated item
Units
R/W
Position
of decimal
point
Description
F14
SO1/2 Active Mode
(SO ACT MODE)
W Closed(On)
Act
Open(Off) Act
Closed(On)
Act
Selects whether SO1/SO2 output
will be set to “On Active” or
“Off Active.”
F15 SI1/2 Active Mode
(SI ACT MODE)
W Short Active
Open Active
Short Active Selects whether SI1/SI2 input
will be set to “Short Active” or
“Open Active.”
F30 Forward Span2
(FWD SPAN2)
WC40
/C41
0 to 40.0001 to 32000 1
Sets flow rate span for forward
No. 2 range
F31 Forward Span3
(FWD SPAN3)
WC40
/C41
0 to 40.0001 to 32000 1
Sets flow rate span for forward
No. 3 range
F32 Forward Span4
(FWD SPAN4)
WC40
/C41
0 to 40.0001 to 32000 1 Sets flow rate span for forward
No. 4 range
F33 Reverse Span1
(REV SPAN1)
WC40
/C41
0 to 40.0001 to 32000 1 Sets flow rate span for reverse
No. 1 range
F34 Reverse Span2
(REV SPAN2)
WC40
/C41
0 to 40.0001 to 32000 1
Sets flow rate span for reverse
No. 2 range
F35 Reverse Span3
(REV SPAN3)
WC40
/C41
0 to 40.0001 to 32000 1
Sets flow rate span for reverse
No. 3 range
F36 Reverse Span4
(REV SPAN4)
WC40
/C41
0 to 40.0001 to 32000 1 Sets flow rate span for reverse
No. 4 range
F40 Auto Range Hys
(AUTO RNG HYS)
W%00 to 15 10 % Sets hysteresis width for
automatic range switching
F41 Bi Direction Hys
(BI DIREC HYS)
W%00 to 8 2 %
Sets hysteresis width for
forward/reverse switching
F12 SI1 Function
(SI1 FUNCTION)
W No Function
0% Singal Lock
Ext Auto Zero
Ext Ttl Preset
Ext Rev Ttl Set
Ext 2 Ranges
Ext 3 Ranges
Ext 4 Ranges
No Function Selects function for the SI1
terminal
F13 SI2 Function
(SI2 FUNCTION)
W No Function
0% Singal Lock
Ext Auto Zero
Ext Ttl Preset
Ext Rev Ttl Set
Ext 2 Ranges
Ext 3 Ranges
Ext 4 Ranges
No Function Selects function for the SI2
terminal
See “6.5 Alarm Function”.
F60 —
(SELF CHECK)
R Good
Error
(7) Item G (Menu G): Alarm Setting items
Menu G contains setting items relevant to alarm output, burnout, alarm record, etc.
Item
Name
Display unit
(BRAIN)
Data range
Display unit
/BRAIN
Default value
(*): Indicated item
Units
R/W
Position
of decimal
point
Description
T0608-1.EPS
G00 Alarm
(ALARM)
G10 Low Alarm
(LOW ALARM)
W%0-110 to 110 -110 Sets level setting value for low
flow rate limit (L)
G11 High Alarm
(HIGH ALARM)
W%0-110 to 110 110 Sets level setting value for high
flow rate limit (H)
G12 Low Low Alarm
(LO LO ALARM)
W%0-110 to 110 -110 Sets level setting value for low-
low flow rate limit (LL)
G13 High High Alarm
(HI HI ALARM)
W%0-110 to 110 110 Sets level setting value for high-
high flow rate limit (HH)
