6. PARAMETER DESCRIPTION
(3) Item C (Menu C): Basic Setting items
Menu C principally contains the basic setting items for the flowtube.
Item
Name
Display unit
(BRAIN)
Data range
Display unit
/BRAIN
Default value
(*): Indicated item
Units
R/W
Position
of decimal
point
Description
T0604-1.EPS
C00
C10
Basic Setup
(BASIC SETUP)
Tag No
(TAG NO)
Sets Tag number up to 16
characters.
ASCII 16 charactersW
C11 Flow Damping
(FLOW DAMPING)
Sets damping time. Linked with
B20.
0.1 to 200.0Ws
mm
inch
1
4
3.0 s
C20 Measure Mode
(MEASURE MODE)
Selects measurement mode for
dual frequency excitation
Standard DF
Enhanced DF
W Standard DF
C21 Low MF
(LOW MF)
Sets low-frequency meter factor for
standard dual frequency excitation
0.0100 to 3.0000W 1.0000 (*)
4C22 High MF
(HIGH MF)
Sets high-frequency meter factor for
standard dual frequency excitation
0.0100 to 3.0000W 1.0000 (*)
4C23 Low MF(EDF)
(LOW MF(EDF))
Sets low-frequency meter factor for
enhanced dual frequency excitation
0.0000 to 3.0000W 1.0000 (*)
4C24 High MF(EDF)
(HIGH MF(EDF))
Sets high-frequency meter factor for
enhanced dual frequency excitation
0.0000 to 3.0000W 1.0000 (*)
C31 Nominal Size Unit
(SIZE UNIT)
Selects the nominal size units for
the flowtube.
mm
inch
Wmm
inch
0 to 2C32 Nominal Size
(NOMINAL SIZE)
Sets flowtube nominal size in
selected unit at C31.
0.99 to 3000.1
0.01 to 120.1
W 100 (*)
C41 Base Time Unit
(TIME UNIT)
Selects time units for the flow
rate span. Linked with B22.
/d
/h
/min
/s
W /s (*)
C40/C41
(B21
/B22)
0 to 4C42 Flow Span
(FLOW SPAN)
Sets flow rate span (with units
from C40 and C41). Linked with
B23.
0.0001 to 32000W1 m/s (*)
C43 Flow Decimal Pnt
(FLOW DECIMAL)
Selects decimal point position for
the display unit's instantaneous
flow rate. Linked with B24.
Auto
0
1
2
3
W Auto (*)
C30 Select Flow Tube
(FLOW TUBE)
Selects the flowtube's model
name.
Note: Select “ADMAG AXF” for
ADMAG AXW flowtube.
ADMAG AXF
ADMAG
ADMAG AE
ADMAG SE
YEWMAG
Calibrator
Other
W
ADMAG AXF
C40 Base Flow Unit
(FLOW UNIT)
Selects flow units for the flow
rate span. Linked with B21.
Ml(Megaliter)
m
3
kl(Kiloliter)
l(Liter)
cm
3
m
t
kg
g
kcf
cf
mcf
Mgal (US)
kgal (US)
gal (US)
mgal (US)
kbbl (US Oil)
bbl (US Oil)
mbbl (US Oil)
ubbl (US Oil)
kbbl (US Beer)
bbl (US Beer)
mbbl (US Beer)
ubbl (US Beer)
ft
klb (US)
lb (US)
Wm (*)
