APPENDIX A
System DO
®
Device RS232 Port Configurations
The 9 pin RS232 Port on the System DO
®
devices (DS-CPU3, DS-12840i, DS-4483 and DS-COM9) can
be used for connection to a PC or a radio fitted with a RS232 data port. It is a DTE configured port. Its
pinouts are shown below together with the standard null modem cable connections. The port may be
configured for a standard range of baud rates and character framing types via the user program. The
RS232 port device is a MAX-202 or MAX-222 type device and these meet the standard EIA-232D and
V.28/V.24 interface specifications.
DB9 Pin Function Pin Specification
Pin 1 Not used
Pin 2 Receive Data in (RXD) Min ± 3V
Max ±30V
Pin 3 Transmit Data out (TXD) Min ± 5V loaded with 3k to GND
Typ ± 8V
Pin 4 Data Terminal Ready out (this is linked active permanently to +12V via 10k resistor)
Pin 5 Ground
Pin 6 Not used
Pin 7 Request to Send out (RTS) Min ± 5V loaded with 3k to GND
Typ ± 8V
Pin 8 Clear to Send in (CTS) Min ± 3V
Max ±30V
Pin 9 Not used
The standard cable to connect an IBM PC compatible computer to these ports should be wired as shown.
The data rate is typically 9600bits/sec.
Device RS232 Port Computer RS232 Port
DB9 Type DB25 Type
Pin 2 (RXD)------------------------------------------------------- Pin 3 (TXD) Pin 2 (TXD)
Pin 3 (TXD) ------------------------------------------------------- Pin 2 (RXD) Pin 3 (RXD)
Pin 5 (GND) ------------------------------------------------------ Pin 5 (GND) Pin 7 (GND)
Pin 7 (RTS) ------------------------------------------------------- Pin 8 (CTS) Pin 5 (CTS)
Pin 8 (CTS) ------------------------------------------------------- Pin 7 (RTS) Pin 4 (RTS)
Note: The RTS/CTS lines are not required unless the port is used in a way that
requires the handshaking lines externally e.g. when connected to a serial printer
and the port is used in ASCII mode.
