Note here that iLink has identified that only files with the extension .lgr are to be displayed, as these are
the only program files that can be loaded into a DS-4483.
Once the correct program has been selected, the file name and directory path will be displayed in the
Program File Name field. This field can be edited at any time up to the time of initiating the [Load]
command.
Start the program upload to the logger by clicking on [Load].
During the loading process, the Progress Bar will report the progress of the file being loaded.
Once started, the upload process can be aborted at any time during the transfer
by clicking the [Abort] button. However, this action will leave the logger with no
program installed. In this event you must successful upload a valid program
before the logger will function normally.
A message will be displayed when the program has been successfully loaded into the datalogger.
The control panel will report the Program Status as ‘IDLE’ and the [Start program] and [Clear Device] buttons
will be enabled.
