Array ID
1. Accept the default array ID (which equates to the sensor number being configured) or uncheck the
box and enter your own array ID.
2. Click [Next] to continue.
Confirmation
1. If you are happy with the settings you have entered, click [Finish] to create the sensor. You can then
review the settings and make any modifications necessary.
2. Alternatively, click [Back] to step back through the various steps and review your settings.
